Name

FURE WEST

Type

Chemical / Oil products tanker

IMO-number

9301873

Call sign

SJLF

Flag

Sweden

Port of registry

Donsö

Previous flag

Faeroe Islands, Nölsoy- Call sign: OZ2100

GT

11.548 t

DWT

Summer: 17.557 t

NT

5.496 t

Length

143,97 m overall

135,75 m between perpendiculars

Breadth

21,50 m

Draught

9,76 m

Keel to mast end

37,00 m

Freeboard

1.753 mm

Depth

12,50 m

Speed

15,4 knots

Built

2006

Date of completion

30/11/2006

Builder

Edward Shipyard

Shanghai

China

Yard number

H135

Hull material

Steel

Hull type

Double hull

Watertight compartments

12

Main engine

1x MaK 7M46D - 4 stroke single acting 7 cylinder 430 x 610 mm combustion engine Mcr 6.300 kW / 8.565 hp at 500 rpm

Built: 2006

Builder: Caterpillar Motoren Rostock GmbH, Rostock - Germany

Propellers

1x Screw propeller controllable pitch - aft at 118 rpm

Boilers

2x Auxiliary thermal oil heater boiler CHO Gesab 121,70 m² - 10,0 bar

1x Thermal oil heater exhaust boiler CHR Gesab 176,00 m² - 10,0 bar

Electric installations

Power voltage: 450 V

Lighting voltage: 220 V

Frequency:60 Hz

Shaft generator

1x 1.250 kVA - 1.000 kW

Generators

3x Main diesel generatorsets each 1.138 kVA - 910 kW - 1.315 hp

Emergency generator

1x Diesel generatorset 313 kVA - 250 kW - 376 hp

Bow thruster

1x 850 kW

Number of cargo tanks

12 + 2 slop tanks

Total cap. cargo tanks 98%

18.833 m³

Cargo handling

12x Cargo pumps each 350 m³/h

2x Slop pumps each 125 m³/h

2x Ballast pumps each 500 m³/h

Discharge capacity

2.500 m³/h

Tank capacities

Ballast: 7.032 m³

HFO: 698 m³

Diesel oil: 114 m³

Fresh water: 52,37 m³

ISM & commercial manager

Furetank Rederi AB

Korsholmebacke 1

SE-430 82 Donso

Sweden

Registered owner

Furetank Rederi AB

Korsholmebacke 1

SE-430 82 Donso

Sweden

Latest data adjustment

14 July 2023
