Cielo Di New York 02

Westerschelde 04 August 2016


Cielo Di New York 01   Cielo Di New York 03   Cielo Di New York 04   Cielo Di New York 06   Cielo Di New York 05
Antwerpen 12/10/14 Antwerpen 02/01/17 Westerschelde 31/02/18 Westerschelde 31/02/18   Westerschelde 31/02/18


Name

CIELO DI NEW YORK

Type

Oil and chemical carrier

IMO-number

9669665

Call sign

9HA3466

Flag

Malta

Port of registry

Valletta

GT

26.746 t registered

DWT

Summer: 39.990 t

NT

10.151 t registered

Length

183,00 m overall

174,00 m between perpendiculars

Breadth

32,20 m moulded

Draught

9,80 m

Freeboard

5.830 mm

Depth

13,60 m

Built

2014

Keel laid

01.07.2013

Date of completion

19.02.2014

Builder

Hyundai Mipo Dockyard Co. Ltd.

Ulsan

South Korea

Yard number

2386

Hull material

Ordinary strength steel

High strength steel

Hull type

Double hull

Watertight bulkheads

13

Main engine

1x MAN-B&W/HHI 6S50ME-B9.2 - 6 cylinder 500 x 2.214 mm diesel engine - 7.280 kW / 8.890 hp at 99,0 rpm

Manufacturer: HHI Engine & Machinery Div.

Propellers

1x fixed pitch propeller - aft at 99,0 rpm

Boilers

1x Composite boiler - 9,0 bar

1x Auxiliary boiler - 9,0 bar

Generators

3x Main diesel generatorsets each 800 kW

Number of cargo tanks

12

Cargo tank capacity

45.662,80 m³ / 45.662,80 t

Number of slop tanks

3

Number of tanks

Ballast: 14

Fuel oil: 9

Lubricating oil: 8

Waste water: 5

Diesel oil: 4

Fresh water: 2

Chain: 2

Sludge: 2

Hydraulic oil: 1

Fixed ballast liquid: 1

Tank capacities

Diesel oil: 219,30 m³ / 197,37 t

Freshwater: 211,2 m³

Fuel oil: 1.198,40 m³ / 1.186,41 t

Hydraulic oil: 7,90 m³ / 16,11 t

Lube oil: 94,70 m³ / 85,20 t

Tank ballast: 21.517,00 m³ / 2.2054,92 t

Lifting equipment

1x Engine Room Crane - SWL 4,0 t

1x Hose Handling Crane - SWL 3,0 t

1x Hose Handling Crane - SWL 10,0 t

1x Provision Crane - SWL 4,0 t

Manager

D'amico Tankers Ltd.

The Anchorage 17-19 Sir John Rogerson's Quay

Dublin 2

Ireland

Operator

D'Amico Società di Navigazione

Registered owner

D'Amico Tankers Ltd.

Ireland

Latest data adjustment

08 December 2014
