Westerschelde 30 June 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 06/04/12 | Westerschelde 06/04/12 | Westerschelde 06/04/12 | Westerschelde 04/08/17 | Westerschelde 25/03/19 | Westerschelde 25/03/19 | |||||
 |
 |
|||||||||
| Westerschelde 15/02/18 | Westerschelde 11/12/16 | |||||||||
|
Name |
TURCHESE |
|
Type |
Oil/ Chemical tanker |
|
IMO-number |
9220354 |
|
Call sign |
IBLE |
|
Flag |
Italy |
|
Port of registry |
Ancona |
|
GRT |
8.428 t |
|
DWT |
Summer: 12.000 t |
|
NRT |
3.934 t |
|
Length |
136,07 m overall |
|
Breadth |
20,40 m moulded |
|
Draught |
Summer: 8,04 m |
|
Moulded L x B x D |
126,50 x 20,40 x 10,30 m |
|
Registered L x B x D |
126,70 x 20,40 x 10,30 m |
|
Freeboard |
2.276 mm |
|
Depth |
10,30 m moulded |
|
Speed |
Service: 14 knots |
|
Built |
2000 |
|
Keel laid |
10/12/1997 |
|
Launch date |
22/05/1999 |
|
Date of completion |
11/01/2000 |
|
Builder |
Cantiere Navale Mario Morini Ancona Italy |
|
Yard number |
264 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
2x Wärtsilä 6R32 - 6 cylinder combustion engine 2.600 KW each at 120,0 rpm connected with 2 ABB-Electric Motors 3.300 kW each |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 510 mm |
|
Propellers |
1x Solid propeller |
|
Boilers |
2x Main boilers (thermal oil) - 0,55 MPa 1x Auxiliary WTB - 1,20 MPa Manufacturer: Bono Energia Canon Bono Energia |
|
Generators |
4x generatorsets total 9.4580 kVA |
|
Bow thruster |
1x Brunvoll FU-6-3-LTA - 520 kW |
|
Number of cargo tanks |
18x Stainless steel centre tanks |
|
Cargo tank capacity 98% |
Tank 1s: 464,00 m³ Tank 1p: 464,20 m³ Tank 2s: 639,70 m³ Tank 2p: 639,20 m³ Tank 3s: 354,70 m³ Tank 3p: 353,30 m³ Tank 4s: 912,60 m³ Tank 4p: 913,70 m³ Tank 5s: 917,10 m³ Tank 5p: 918,50 m³ Tank 6s: 1.101,50 m³ Tank 6p: 1/101,30 m³ Tank 7s: 366,70 m³ Tank 7p: 366,60 m³ Tank 8s: 917,50 m³ Tank 8p: 916,40 m³ Tank 9s: 988,00 m³ Tank 9p: 986,40 m³ Total: 13.543,40 m³ |
|
Number of slop tanks 98% |
2 Tank 1s: 111,0 m³ Tank 1p: 111,0 m³ |
|
Pumps |
14x Framo deepwell hydraulic driven - 250 m³/h 4x Framo deepwell hydraulic driven - 1.00 m³/h 1x Framo portable spare pump - 70 m³/h 2x Framo deepwell hydraulic driven for slop tanks each 50 m³/h |
|
Tank capacities |
HFO: 650,0 m³ MDO: 110,00 m³ Fresh water: 112,10 m³ |
|
Manager |
Finbeta SpA Via S. S. 29 Nazionale del Piemonte Savona SV Italy |
|
Owner |
Finbeta SpA Via S. S. 29 Nazionale del Piemonte Savona SV Italy |
|
Renamed |
2021 Karlica Turkey, Istanbul - Call sign: TCA6570 Owner: Beykim Petrolculuk Gemi Isletmeciligi Sanayi Ve Ticaret A.S. , Istanbul - Turkey Manager: Beykar Denizcilik Gemi Kiralama Turizm Nakliyat Petrolculuk Ticaret A.S., Besiktas - Turkey |
|
Latest data adjustment |
26 April 2023 |
