Name |
STOLT BRELAND |
|
Type |
Tanker for chemicals & oil products |
|
IMO-number |
9414084 |
|
Call sign |
ZCXH |
|
Flag |
Cayman Islands |
|
Port of registry |
George town |
|
GT |
25.881 t |
|
DWT |
Summer: 43.475 t |
|
NT |
13.418 t |
|
Length |
182,72 m overall 175,22 m between perpendiculars |
|
Breadth |
32,24 m extreme |
|
Draught |
11,88 m |
|
Air draft |
47,00 m |
|
Depth |
15,60 m moulded |
|
Speed |
15,0 knots |
|
Built |
2010 |
|
Keel laid |
08.12.2008 |
|
Launch date |
08.01.2010 |
|
Date of completion |
12.03.2010 |
|
Builder casco |
Wadan Yards Okean OJSC |
|
Builder completion |
STX Norway Florø AS |
|
Yard number |
154 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN B&W/STX 7S50MC-C8.1 - 2 stroke single acting 7 cylinder diesel engine - 11.060 kW / 15.037 bhp at 127,0 rpm Builder: MAN B&W Diesel GmbH, Augsburg - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated MISSION XW 2x Auxiliary boiler, oil/gas fired Mission OM Builder: Aalborg Industries, Aalborg - Denmark |
|
Generators |
2x MAN 7L21/31 main diesel generatorsets |
|
Emergency generator |
1x Volvo Penta D9 diesel generatorset |
|
Bow thruster |
1 |
|
Number of tanks |
39 15x Centre tanks 24x Wing tanks |
|
Cargo tank capacity |
44.495 m³ |
|
Cargo separations |
39 |
|
Pumps |
39x pumps total capacity of 12.925 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 86,10 m |
|
Tank capacities |
Ballast: 16.468 m³ Bunker: 1.834 t |
|
Anchor equipment |
Length: 632,50 m Diameter: 73 mm |
|
Manager |
Stolt Tankers B.V. The Netherlands |
|
Operator |
STJS - Stolt Tankers Joint Service |
|
Registered owner |
Stolt Breland B.V. |
|
Previous owners |
2010 - 2010 Stolt Tankers B.V. |
|
Latest data adjustment |
31 August 2015 |
