Westerschelde 03 July 2019 |
 |
| Westerschelde 22/02/14 |
|
Name |
THUN GARLAND |
|
Previous names |
2009 - 02/2013 Bro Garland |
|
Type |
Tank for oil and chemicals |
|
IMO-number |
9393345 |
|
Call sign |
PBLW |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
4.212 t |
|
DWT |
Summer: 7.559 t |
|
NT |
1.911 t |
|
Length |
116,35 m overall 110,90 m between perpendiculars |
|
Breadth |
15,00 m |
|
Draught |
Summer: 6,76 m |
|
Keel to mast end |
27,85 m |
|
Freeboard |
2.559 mm |
|
Depth |
9,30 m moulded |
|
Speed |
13,5 knots |
|
Built |
2009 |
|
Launch date |
21/03/2009 |
|
Date of completion |
28/05/2009 |
|
Builder |
Ferus Smit Scheepswerf B.V. Hoogezand The Netherlands |
|
Yard number |
387 |
|
Hull material |
Special steel |
|
Hull type |
Double hull |
|
Watertight compartments |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 7L32C - 4 stroke single acting 7 cylinder 320 x 400 mm combustion engine 3.360 kW / 4.565 bhp at 720 rpm Built: 06/2008 Builder: Wärtsilä Finland OY, Vaasa - Finland |
|
Propellers |
1x Screw propeller controllable pitch - aft at 176 rpm |
|
Shaft generator |
1x 419 kVA - 335 kW |
|
Generators |
3x Main diesel generatorsets each 435 kVA - 348 kW - 503 hp |
|
Emergency generator |
1x Diesel generatorset 63 kVA - 50 kW - 65 hp |
|
Bow thruster |
1x 260 kW |
|
Number of tanks |
9 |
|
Total capacity of tanks |
8.066 m³ |
|
Number of pumps |
9x Cargo pumps each 300 m³/h |
|
Tank capacities |
Fuel oil: 380,4 m³ |
|
Commercial manager |
Erik Thun AB Ostra Hamnen 7 SE-531 32 Lidkoping Sweden |
|
ISM manager |
Marin Ship Management B.V. Hogelandsterweg 14 9936 BH Farmsum The Netherlands |
|
Owner |
Thun Tankers BV, Delfzijl - The Netherlands Care of Erik Thun AB (Thunship Management Holland) Ostra Hamnen 7 SE-531 32 Lidkoping Sweden |
|
Previous names & owners |
05/2009 - 02/2013 Bro Garland - Bro Garland B.V., Delfzijl - The Netherlands |
|
Latest data adjustment |
06 July 2022 |
