Name |
TRAVIATA |
|
Type |
Chemical tanker - Oil product tanker |
|
IMO-number |
9684122 |
|
Call sign |
5BXS4 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flag |
2014 - 2018 G.D. Luxembourg, Luxembourg City - Call sign: LXTA |
|
GT |
4.696 t |
|
DWT |
Summer: 6.325,9 t |
|
NT |
1.879 t |
|
Length |
104,96 m overall 99,00 m between perpendiculars |
|
Breadth |
17,23 m extreme 17,00 m moulded |
|
Draught |
7,45 m |
|
Keel to mast end |
36,99 m |
|
Depth |
9,35 m |
|
Speed |
12,8 knots |
|
Built |
2014 |
|
Keel laid |
24/10/2013 |
|
Launch date |
28/04/2014 |
|
Delivery date |
13/10/2014 |
|
Builder |
Tersan Tersanecilik Sanayi ve Ticaret A.S. Tuzla - Istanbul Turkey |
|
Yard number |
1055 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 7L32/44CR - 4 stroke 7 cylinder 320 x 440 mm combustion engine 3.920 kW at 750 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
2x Thermal oil heater, oil fired 1x Thermal oil heater, steam heated 1x Thermal oil heater, exhaust heated |
|
Shaft generator |
1x 750 kVA |
|
Generators |
3x MAN D2842 LE301 main diesel generatorsets each 737 kVA |
|
Emergency generator |
1x MAN D2866 LXE20 diesel generatorset |
|
Bow thruster |
1x 428 kW |
|
Number of tanks |
14 |
|
Tank capacity |
6.800 m³ |
|
Number of pumps |
12x Cargo pumps each 200 m³/h 2x Cargo pumps each 125 m³/h |
|
Anchor equipment |
Length: 495,00 m Diameter: 44 mm |
|
Crew size |
13 |
|
ISM & commercial manager |
GEFO Gesellschaft für Oeltransporte mbH Raboisen 5 D-20095 Hamburg Germany |
|
Registered owner |
GEFO Gesellschaft für Oeltransporte mbH Raboisen 5 D-20095 Hamburg Germany |
|
Latest data adjustment |
21 August 2022 |
