Name |
MINERVA LEO |
|
Type |
Tanker for oil and chemicals |
|
Transport type |
Isothermal |
|
Main products |
Chemicals |
|
IMO-number |
9723289 |
|
Call sign |
SVCD6 |
|
Flag |
Greece |
|
Port of registry |
Piraeus |
|
GT |
24.090 t registered |
|
DWT |
Summer: 39.070 t |
|
NT |
10.389 t registered |
|
Light ship displacement |
9.550 t |
|
Length |
184,27 m overall 176,13 m between perpendiculars |
|
Breadth |
27,40 m |
|
Draught |
11,91 m |
|
Freeboard |
5.713 mm |
|
Depth |
17,60 m |
|
Speed |
14,4 knots |
|
Built |
2015 |
|
Keel laid |
26/05/2015 |
|
Launch date |
07/07/2015 |
|
Date of completion |
14/10/2015 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. South Korea |
|
Yard number |
2523 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/HHI 6S50ME-B9 - 2 stroke single acting 6 cylinder 500 x 2.214 mm combustion engine 7.290 kW / 9.911 hp at 99,0 rpm Built: 26/05/2015 Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller- aft at 99,0 rpm |
|
Boilers |
1x CHO Kangrim 233,00 m² - 8,8 bar 1x CHM Kangrim 213,40 m² - 8,8 bar |
|
Generators |
3x Hyundai/Himsen 6H21/32 - 4 stroke 6 cylinder 201 x 320 diesel engines each 960 kW / 1.204 hp connected with generators each 900 ekW /1.125 kVA |
|
Emergency generator |
1x Cummins 6CT-8.3-D(M) diesel generatorset 150 kVA - 120 kW - 177 hp |
|
Number of tanks |
10 + 2 slop tanks |
|
Total cap. of tanks 98% |
42.712,30 m³ excluding slop tanks |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
1.080,20 m³ |
|
Pumps |
10x Cargo pumps 500 m³/h each 2x slop cargo pumps 300 m³/h each 2x Spare pumps 200 m³/h each |
|
Tank capacities |
Fuel oil: 1.175,9 m³ Ballast: 18.587,6 m³ |
|
Anchor equipment |
Length: 635,50 m Diameter: 68 mm |
|
Lifting equipment |
1x Cranes - SWL 10,0 t |
|
Crew size |
23 persons |
|
ISM & commercial manager |
Minerva Marine Inc. 141-143 Vouliagmenis Avenue Voula 166 73 Athens Greece |
|
Owner |
Ronine Finance Company Care of Minerva Marine Inc , 141-143, Vouliagmenis Avenue, Voula 166 73 Athens, Greece |
|
Latest data adjustment |
06 October 2021 |
