Name |
HEATHER |
|
Previous names |
2010 - 04/2011 Sarah Dee |
|
Type |
Tanker for oil & chemicals |
|
Main products |
Chemicals |
|
IMO-number |
9514456 |
|
Call sign |
9HA2297 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
5.655 t |
|
DWT |
Summer: 8.402,16 t |
|
NT |
2.634 t |
|
Length |
124,10 m overall 115,97 m between perpendiculars |
|
Breadth |
17,20 m |
|
Draught |
Summer: 7,19 m 4,77 m ballast |
|
Height from keel to mast |
36,55 m |
|
Air draft |
30,78 m in ballast 29,35 m loaded condition |
|
Freeboard |
2.016 mm |
|
Depth |
9,20 m moulded |
|
Speed |
Max.: 15,0 knots Service: 13,0 knots Economic: 12,5 knots |
|
Built |
2010 |
|
Date of completion |
11/03/2010 |
|
Builder |
Turker Gemi Yapim San. Tic. A.S. Turkey |
|
Yard number |
16 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32C - 4 stroke 8 cylinder 320 x 480 mm combustion engine 4.000 kW / 5.396 bhp at 600 rpm Built: 11/12/2008 Builder: Caterpillar Motoren GmbH & Co. KG - Germany |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
2x CHO S-MAN AB 40,00 m² - 12,0 bar 1x CHR S-MAN AB 105,00 m² - 12,0 bar |
|
Shaft generator |
1x 1.375 kVA - 1.100 kW |
|
Generators |
2x Main diesel generatorsets each 606 kVA - 485 kW - 842 hp 1x Main diesel generatorset 731 kVA - 585 kW - 842 hp |
|
Emergency generator |
1x Diesel generatorset 250 kVA - 200 kW - 281 hp |
|
Bow thruster |
1x 584 hp |
|
Number of tanks |
14 |
|
Total cap. of tanks 98% |
8.931,14 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
293,40 m³ |
|
Number of segregations |
14 |
|
Pumps |
10x Centrifugal cargo pumps each 200 m³/h 2x Centrifugal cargo pumps each 150 m³/h 2x Ballast pumps each 250 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 66,63 m Distance from stern to centre manifold: 57,41 m Distance between manifolds: 750 mm Distance from ship side to manifold: 2.537 mm Distance from deck / tray to manifold: 2,30 m |
|
Tank capacities |
Fuel oil: 403,32 m³ Ballast: 3.611,83 m³ |
|
Lifting equipment |
1x SWL 6,0 t for cargo operations 1x SWL 6,0 t for service |
|
Manager |
Atlantik Denizcilik Gayrettepe, Itri Sok. 10/A Beşiktaş, Istanbul Turkey |
|
Operator |
Atlantik Denizcilik Tic ve San A.S. |
|
Registered owner |
Hunter Navigation Inc. C/O Atlantik Denizcilik Tiv. VE San.A.S. |
|
Renamed |
10/2022 Anton Gibraltar - Call sign: ZDSH3 Owner: Reederei TMS Anton E. GmbH & Co. KG - Germany Manager: Carl F. Peters GmbH & Co, Hamburg - Germany |
|
Latest data adjustment |
07 June 2024 |
