Name |
SLOMAN HERMES |
|
Type |
Oil tanker/Chemical tanker |
|
IMO-number |
9466738 |
|
Call sign |
V2HV6 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
Previous flag |
2012 - 2017 Antigua & Barbuda, St. John's - Call sign: V2FY5 2017 - 2019 Germany - Call sign: DHUM2 2019 - 2023 Malta, Valletta - Call sign: 9HA5035 |
|
GT |
11.311 t registered Suez: 12.016,35 t |
|
DWT |
Summer: 16.418 t |
|
NT |
4.961 t registered Panama; 9.509 t Suez: 9.862,23 t |
|
Light ship |
5.682 t |
|
Length |
145,15 m overall 135,60 m between perpendiculars |
|
Breadth |
23,03 m extreme |
|
Draught |
8,80 m |
|
Keel to mast end |
39,55 m |
|
Freeboard |
3.717 mm |
|
Depth |
12,50 m moulded |
|
Speed |
13,0 knots |
|
Built |
2012 |
|
Keel laid |
16/03/2009 |
|
Launch date |
24/05/2010 |
|
Date of completion |
29/06/2012 |
|
Builder |
Jiangxi Jiangzhou Union Shipbuilding Co., Ltd. China |
|
Yard number |
JZ1024 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
12 |
|
Main engine |
1x MAN-B&W 6S35MC-MK7 - 2 stroke 6 cylinder 350 x 1.400 mm combustion engine 4.440 kW / 6.037 hp at 173 rpm Manufacturer: STX Engine Co., Ltd. |
|
Propellers |
1x Fixed pitch mono-block propeller |
|
Boilers |
2x Auxiliary boiler, oil/gas fired - 7,0 bar 1x Auxiliary boiler, exhaust gas heated (Economizer) - 7,0 bar Manufacturer: Zhangjiagang Greens Shazhou Boiler Co., Ltd. |
|
Generators |
3x Daihatsu 5DK-20 - 5 cylinder 200 x 300 mm combustion engines each 660 kW at 900 rpm connected with generators each 600 kW Manufacturer: CSIC Electrical Machinery Science & Technology Co. / CSIC Electrical Machinery Science & Technology Co. |
|
Emergency generator |
1x AGCO Sisu 634 diesel generatorset |
|
Bow thruster |
1x 750 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 100% |
19.969.69 m³ |
|
Number of pumps |
12x Cargo pumps each 300 m³/h |
|
Number of tanks |
Ballast: 13 Fuel oil: 11 Lubricating oil: 8 Fresh water: 5 Diesel oil: 4 Chain: 2 Waste water: 1 |
|
Tank capacities 100% |
Diesel Oil: 92,12 m³ Freshwater: 659,57 m³ Fuel oil: 781.02 m³ Lube Oil: 85,35 m³ Tank Ballast: 7.720,64 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 56 mm |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 10,0 t 1x Rescue boat, Life raft & Provision crane - SWL 2,0 t Manufacturer:Zhenjiang Marine Auxiliary Machinery Works 1x Engine room overhead crane - SWL 2,0 t Manufacturer: Jiangyin Oya Marine Machinery Co., Ltd. |
|
ISM & commercial manager |
Sloman Neptun Schiffahrts-Aktiengesellschaft Langenstr. 44 D-28195 Bremen Germany |
|
Registered owner |
MT Sloman Hermes Schifffahrtsgesellschaft mBH & Co Care of Sloman Neptun Schiffahrts-Aktiengesellschaft, Langenstrasse 44 28195 Bremen Germany |
|
Latest data adjustment |
01 August 2024 |
