Name |
RYSTRAUM |
|
Type |
Tanker for chemicals & oil products |
|
IMO-number |
9391000 |
|
Call sign |
LAKN6 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
7.243 t |
|
DWT |
Summer: 9.597 |
|
NT |
3.078 t |
|
Length |
129,00 m overall 120,04 m between perpendiculars |
|
Breadth |
19,20 m extreme |
|
Draught |
7,73 m |
|
Freeboard |
2.312 mm |
|
Depth |
9,80 m |
|
Speed |
Service: 14,0 knots Max.: 17,5 knots |
|
Built |
2012 |
|
Keel laid |
12/06/2007 |
|
Launch date |
26/10/2008 |
|
Date of completion |
27/03/2012 |
|
Builder casco |
Cantiere Navale De Poli SpA Venezia Italy Yard number: 243 |
|
Builder completion |
Brodogradjevna Industrija 3.MAJ d.d. Rijeka Croatia Yard number: 715 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 9L32/40 - 4 stroke 9 cylinder diesel engine 4.320 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated - 10,0 bar 1x Auxiliary boiler, oil/gas fired - 10,0 bar Builder: Garioni Naval Castelmella - Brescia Italy |
|
Generators |
3x Mitsubishi D34A-MS main diesel generatorsets Builder: Mitsubishi Heavy Industries Ltd., Sagamihara Machinery Works |
|
Emergency generator |
1x Volvo Penta D9 diesel generatorset |
|
Bow thruster |
1x Jastram BU90F |
|
Cargo tank capacity 98% |
10.605 m³ |
|
Tank capacities |
Ballast: 4.146,9 m³ |
|
Anchor equipment |
Length: 522,50 m Diameter: 50 mm |
|
Manager |
Utkilen AS Strandgaten 197 5004 Bergen Norway |
|
Registered owner |
Utkilen Chemtrans AS Strandgaten 197 5004 Bergen Norway |
|
Latest data adjustment |
31 October 2022 |
