Aurelia - IMO 9327102

Antwerpen 28 August 2018

Name

AURELIA

Type

Oil tanker / Chemical tanker

IMO-number

9327102

Call sign

DDNW

Flag

Germany

Port of registry

Bremen

GT

16.683 t

DWT

Summer: 20.025 t

NT

6.395 t

Length

168,00 m overall

160,80 m between perpendiculars

Breadth

26,56 m extreme

26,40 m moulded

Draught

9,02 m

Forecastle

11,92 m

Poop

16,73 m

Freeboard

4.764 mm

Depth

13,81 m

Speed

15,5 knots

Built

2006

08/2009 rebuild

Keel laid

20/12/2004

Launch date

13/08/2005

Date of completion

08/02/2006

Builder

3. Maj Brodogradiliste d.d.

Rijeka

Croatia

Yard number

689

Hull material

Mild steel

Hull type

Double hull, double bottom, continuous from peak to peak bulkhead

Watertight bulkheads

10

Continuous decks

1

Main engine

1x MaK 6M32C - 4 stroke 6 cylinder 320 x 480 mm combustion engine 3.000 kW at 600 rpm

1x MaK 8M32C - 4 stroke 8 cylinder 320 x 480 mm combustion engine 4.000 kW at 600 rpm

Total: 7.000 kW / 9.511 hp

Build: 11/05/2005

Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany

Propellers

1x Schottel SCP-1414 XW controllable pitch propeller aft at 127,0 rpm

Boilers

1x Auxiliary boiler, composite

1x Auxiliary boiler, oil/gas fired

Manufacturer: Aalborg

Generators

2x MAN-B&W 6L23/30H main combustion engines each 1.020 kW at 900 rpm connected with 2 Uljanik generators FC6-564-6 each 1.500 kVA

Emergency generator

1x MAN D2866TE diesel engine 215 kW connected with Uljanik ADB HCM434D 192 kW

Bow thruster

1x Schottel Type STT-3CP - 800 kW at 1.770 rpm

Number of tanks

12

Cargo tank capacity 98%

No. 1 P + S: 3.795 m³

No. 2 P + S: 4.724 m³

No. 3 P + S: 4.924 m³

No. 4 P + S: 5.575 m³

No. 5 P + S: 3.212 m³

No. 6 P + S: 5.831 m³

Slop tanks P + S: 535 m³

Total: 28.596 m³

Number of slop tanks

2

Pumps

• 12x Marflex Submerged cargo pumps, electrically driven type MDPD 150 each 350 m³/h

• 3x Marflex Submerged slop / Residual pumps, Electrically driven type MDPD 80 each 100 m³/h

• 1x Marflex Portable cargo pump, hydraulically driven type: TK 150 - 150 m³/h

• 2x TTK Ballast pumps, electrically driven type: BPV 375 - 250 H39 each 500 m³/h

• 1x TTK Tank cleaning pump, electrically driven type: NPm 65-250 - 100 m³/h

Manifolds

Distance bow to centre manifold: 81,60 m

Tank capacities 100%

Fuel: 1.052 m³

Ballast: 12.214,1 m³

Anchor equipment

3x Anchors weight each 6.450 kg

Length: 605,00 m

Diameter: 62 mm

Lifting equipment

1x Hydraulic hose handling crane - SWL 10,0 t

Manager

Carl Büttner Shipmanagement GmbH

Herrlichkeit 2

28199 Bremen

Germany

Registered owner

Sechste Büttner Schiffahrtsges. mbH & Co. KG

Germany

Renamed

01/2024 Samuda

Bangladesh, Chattogram - Call sign: S2CO9

Manager: Ocean Wave Ship Management Ltd.,Dhaka - Bangladesh

Owner: Samuda Shipping Ltd., Dhaka - Bangladesh

Latest data adjustment

04 June 2024
