Chembulk Savannah - IMO 9248461

Antwerpen 11 September 2018

Name

CHEMBULK SAVANNAH

Type

Tanker for chemicals & oil products

IMO-number

9248461

Call sign

V7OP7

Flag

Marshall Islands

Port of registry

Majuro

Previous flags

2002 - 2015 Republic of Singapore, Singapore City - Call sign: 9VFA2

GT

15.148 t

Suez: 16.086,85 t

DWT

Summer: 24.404 t

Winter: 23.672,65 t

NT

7.022 t

Panama: 12.697 t

Displacement

Summer: 31.560,47 t

Winter: 30.829,12 t

Length

153,20 m overall

144,20 m between perpendiculars

Breadth

25,03 m extreme

Draught

Summer: 10,62 m

Winter: 10,40 m

Keel to masthead

36,17 m

Air draft

Lightship: 33,52 m

Normal ballast: 29,10 m

Summer deadweight: 25,55 m

Freeboard

Summer: 4.620 mm

Winter: 4.840 mm

Depth

15,23 m moulded

Speed

14,8 knots laden / economic: 13,5 knots

15,0 knots ballast / economic: 12,5 knots

Built

2002

Keel laid

20/05/2001

Launch date

18/10/2001

Date of completion

02/01/2002

Builder

Kitanihon Shipbuilding Co., Ltd.
Hachinohe
Japan

Yard number

331

Hull material

Steel

Hull type

Double hull

Main engine

Akasaka/Mitsubishi 6UEC52LS - 2 stroke 6 cylinder combustion engine 7.080 kW

Propellers

1x Fixed mono-block propeller

Boilers

1x Auxiliary boiler, oil/gas fired

1x Auxiliary boiler, exhaust gas heated

Manufacturer: Miura

Generators

3x Yanmar 6N21L-EV main diesel generatorsets each 800 kW

Bow thruster

1x 700 kW / 938 bhp

Number of cargo tanks

2

Total tank capacity 98%: 26.255,67 m³

Cargo tank capacity

Seg#1: 2.414,91 m³ (1W)
Seg#2: 1.321,06 m³ (2W)
Seg#3: 2.615,09 m³ (3W)
Seg#4: 1.874,02 m³ (4W)
Seg#5: 3.444,19 m³ (5W)
Seg#6: 1.255,80 m³ (6W)
Seg#7: 3.840,98 m³ (7W)
Seg#8: 1.674,85 m³(8W)
Seg#9: 2.658,62 m³ (9W)
Seg#10: 3.769,80 m³ (10W)
Seg#11: 1.386,35 m³ (11W)

Pumps

24x Centrifugal cargo pumps each 250 m³/h

2x Centrifugal ballast pumps each 500 m³/h

Manifolds

Distance bridge front to centre of manifold: 50,50 m

Bow to centre manifold: 76,60 m

Stern to centre manifold: 76,60 m

Distance between cargo manifold centres: 500 mm

Distance ships rail to manifold: 4.350 mm

Distance manifold to ships side: 4.600 mm

Top of rail to centre of manifold: 700 mm

Distance main deck to centre of manifold: 2.100 mm

Spill tank grating to centre of manifold: 900 mm

Tank capacities

Fuel oil: 1.011,53 m³

Diesel oil: 97,60 m³

Anchor equipment

Length: 577,50 m

Diameter: 60 mm

Lifting equipment

1x Crane - SWL 10,0 t midships - centre

Manager

Thome Ship Management Pte. Ltd.

Technical operator

Thome Ship Management Pte Ltd
16 Raffles Quay, #43-01 Hong Leong Building

Singapore 048581
Republic of Singapore

Commercial operator

Chembulk Maritime Pte Ltd.
The Delamar 175 Rennell Drive Southport, CT 06890
United States

Owner

Chembulk Savannah LLC

The Trusted Company Of Marshall Islands, Inc.Trust Company Complex, Ajeltake Road, Ajeltake Island
Majuro
Republic Of Marshall Island

Registered owner

Chembulk Savannah LLC

The Trusted Company Of Marshall Islands, Inc.Trust Company Complex, Ajeltake Road, Ajeltake Island
Majuro
Republic Of Marshall Island

Disponent owner

Chembulk Ocean Transport LLC
Chembulk Ocean Transport LLC. The Delamar,175 Rennell DriveSouthport, CT 06890

Latest data adjustment

13 October 2018
