Terneuzen, The Netherlands 16 August 2019 |
 |
| Westerschelde 17/11/18 |
|
Name |
EK-RIVER |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9808259 |
|
Call sign |
LAEK8 |
|
Flag |
Norway |
|
Port of registry |
Arendal |
|
GT |
14.256 t |
|
DWT |
Summer: 19.884 t Winter: 19.226 t |
|
NT |
6.468 t |
|
Length |
153,93 m overall 150,10 m between perpendiculars |
|
Breadth |
23,75 m extreme |
|
Draught |
Max: 9,76 m 6,50 m in ballast |
|
Depth |
13,76 m |
|
Speed |
12,9 knots Max: 15,0 knots |
|
Built |
2018 |
|
Keel laid |
25/06/2015 |
|
Launch date |
05/12/2017 |
|
Date of completion |
10/08/2018 |
|
Builder |
Chengxi Shipyard Co., Ltd. Jiangyin China |
|
Yard number |
CX0377A |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6G45ME-C - 2 stroke 6 cylinder 450 x 2.250 mm combustion engine Mcr 5.500 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated 2x Thermal oil heater, oil fired |
|
Generators |
4x MAN 6L16/24 main diesel generatorsets |
|
Emergency generator |
1x Volvo D9 diesel generatorset |
|
Bow thruster |
1x Kongsberg TT 1850 AUX fixed pitch propeller |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 98% |
20.020,4 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
334,9 m³ |
|
Pumps |
12x Deepwell electrical driven cargo pumps each 330 m³/h 2x Deepwell electrical driven cargo pumps each 100 m³/h 2x Ballast pumps each 250 m³/h |
|
Cargo discharge capacity |
1.980 m³/h |
|
Tank capacities |
HFO: 540,9 m³ - 98% Diesel oil: 163,8 m³ Ballast: 8.288,3 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t |
|
Commercial manager |
Ektank AB Stora Badhusgatan 18-20 SE-411 21 Gothenburg Sweden |
|
ISM manager |
OSM Ship Management AS Svinoddveien 12 4836 Arendal Norway |
|
Registered owner |
Ekships AB, 430 82 Donsø - Sweden Care of Ektank AB Stora Badhusgatan 18-20 SE-411 21 Gothenburg Sweden |
|
Latest data adjustment |
07 April 2022 |
