| Westerschelde |
 |
| Westerschelde 20/11/19 |
|
Name |
ELISALEX SCHULTE |
|
Type |
Oil and chemical carrier |
|
IMO-number |
9439876 |
|
Call sign |
9V9154 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
11.246 t Suez: 11.956,22 t |
|
DWT |
Summer: 16.418 t |
|
NT |
4.961 t Suez: 9.802,1 t |
|
Length |
145,15 m overall 135,60 m between perpendiculars |
|
Breadth |
23,28 m extreme 23,00 m moulded |
|
Draught |
Max: 8,80 m |
|
Freeboard |
3.714 mm |
|
Depth |
12,50 m moulded |
|
Speed |
Service: 13,5 knots |
|
Built |
2011 |
|
Keel laid |
20/06/2008 |
|
Launch date |
12/04/2011 |
|
Delivery date |
10/11/2011 |
|
Builder |
Jiangzi Jiangzhou Unite Shipbuilding Co Ltd. Juijiang China |
|
Yard number |
JZ1016 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6S35MC-MK7 - 2 stroke 6 cylinder 350 x 1.400 mm combustion engine 4.440 kW - 5.982 hp at 173,0 rpm Manufacturer: STX Engine Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller - aft at 173,0 rpm Manufacturer: Wärtsilä Cme Zhenjiang Propeller Co., Ltd. |
|
Boilers |
2x Fired boiler type LSZ7-0.7 - 7,0 bar 1x Unfired exhaust gas boiler type GFL100-0.7 - 7,0 bar Manufacturer: Zhangjiagang Greens Shazhou Boiler Co., Ltd. |
|
Generators |
3x Daihatsu 5DK-20E - 4 stroke 5 cylinder 200 x 300 mm diesel engines each 660 kW at 900 rpm coupled with generators each 600 kW Manufacturer: Anqing Cssc Diesel Engine Co Ltd. / CSIC Electrical Machinery Science & Technology Co., Ltd. |
|
Bow thruster |
1x Tunnel thruster 739 kW / 1.005 bhp |
|
Cargo tank capacity 98% |
19.649,64 m³ |
|
Slop tank capacity 98% |
431 m³ |
|
Tank capacities |
Ballast: 7.720,64 m³ Fuel oil: 682,49 m³ Lub oil: 83,63 m³ Diesel oil: 92,12 m³ Fresh water: 659,57 m³ |
|
Lifting equipment |
1x Hydraulic slewing crane - SWL 10,0 t 1x Slewing crane & boat/raft davit - SWL 2,0 t Manufacturer: Zhenjiang Marine Auxiliary Machinery Works 1x Engine room crane - SWL 2,0 t Manufacturer: Jiangyin Oya Marine Machinery Co., Ltd. |
|
Manager |
Bernhard Schulte GmbH & Co. KG |
|
Registered owner |
Clementi Park Shipping Co., Pte Ltd. 108 Middle road #9 The Prospex Singapore 188967 Republic of Singapore |
|
Latest data adjustment |
13 April 2022 |
