| Zeebrugge 20 April 2009 |
 |
 |
|
| Zeebrugge 30/03/09 | Zeebrugge 30/03/09 | |
|
Name |
MCS ALIX |
|
Type |
Tug - Shoalbuster 2609 |
|
IMO-number |
9364538 |
|
Call sign |
MKWU2 |
|
Flag |
Scotland - United Kingdom |
|
Port of registry |
Glasgow |
|
GT |
161,25 t |
|
DWT |
300 t |
|
Length |
26,02 m |
|
Breadth |
9,12 m |
|
Draught |
Summer: 2,65 m |
|
Speed |
11,5 knots |
|
Built |
2005 |
|
Builder |
Damen Shipyards |
|
Yard number |
1565 |
|
Main engine |
2x Caterpillar 3508 BTA diesel engines- 1.642 kW / 2.234 bhp |
|
Propulsion |
Twin screw fixed pitch propellers in OPTIMA nozzles |
|
Electrical system |
230/400 VAC 50 Hz |
|
Generators |
2x John Deere diesel generatorsets each 87 kVA |
|
Bow thruster |
150 hp hydraulic |
|
Bollard pull |
29,1 t |
|
Main towing winch |
40 t - wire capacity 600 m x 36 mm |
|
A-H winch |
40 t - 200 x 36 mm wire with stern roller |
|
Auxiliary winch |
Tugger winch 10 t |
|
Deck area / strength |
8,00 x 8,00 m timber clad, 5 t/m² |
|
Deck |
Large aft deck with 4,00 m stern roller |
|
Tank capacities |
Diesel oil: 130 m³ |
|
Crane |
Heila 140 t/m hydraulic crane |
|
Accommodation |
Air conditioning accommodation for 6 crew with sanitary facilities |
|
Crew |
5 |
|
Operator |
Maritime Craft Services (Clyde) Ltd. |
|
Owner |
Maritime Craft Services (Clyde) Ltd. |
