| Zeebrugge 20 April 2009 |
 |
| Zeebrugge 11/04/09 |
|
Name |
MCS LENIE |
|
Type |
Tug - Survey - Damen shoalbuster 2709 |
|
IMO-number |
9522221 |
|
Call sign |
2BON3 |
|
Flag |
Scotland - United Kingdom |
|
Port of registry |
Glasgow |
|
GT |
289 t |
|
GRT |
141,63 t |
|
NT |
142 t |
|
Length |
27,19 m overall |
|
Breadth |
9,10 m over all |
|
Draught |
Summer: 2,63 m |
|
Freeboard |
Summer: 1.000 mm |
|
Depth |
3,60 m |
|
Speed |
Free running speed 11,5 knots |
|
Built |
2008 |
|
Date of build |
29.11.2008 |
|
Builder casco |
Kozle Shipyard Kedzierzyun |
|
Builder completion |
Damen Shipyards Hardinxveld |
|
Yard number |
571597 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
4 |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar Series 3512 TA - 12 Cylinder 4 stroke 170 x 190 mm diesel engine - output 3.040 hp / 2.237,44 kW total at 1.600 rpm |
|
Propeller |
1x Screw propeller solid - at 255 rpm |
|
Electrical system |
230/400 V - 50 Hz |
|
Generators |
2x Caterpillar C-4.4 TA diesel generatorsets each - 97,5 kVA - 78 kW - 102 hp |
|
Bow thruster |
Hydraulic 200 hp |
|
Compressor |
320 l/min |
|
Bollard pull |
40,0 t |
|
Towing / AH winch |
Ridderinkhof 65 / 100 t waterfall type |
|
Auxiliary winch |
Tugger winch 8 t, capstan 2 |
|
Deck area / strength |
9,00 x 8,00 m / 5,0 t/m² |
|
Tank capacities |
Fuel oil: 118,54 m³ |
|
Hydraulic crane |
Heila HLRM-140-SL |
|
Accommodation |
Air-conditioned accommodation for 7 crew in 5 cabins |
|
Crew |
5 |
|
Owner |
MCS - Maritime Craft Services (Clyde) Ltd. |
