| Vlissingen, The Netherlands 08 November 2013 |
 |
 |
 |
 |
 |
 |
|||||
| Vlissingen 27/08/15 | Antwerpen 19/08/16 | Terneuzen 02/08/17 | Terneuzen 02/08/17 | Antwerpen 23/10/18 | Zeebrugge 28/11/20 | |||||
|
Name |
MULTRATUG 22 |
|
Previous names |
2001 - 2004 Atlas Z |
|
Type |
Tug boat - Coastal services |
|
IMO-number |
8662787 |
|
Call sign |
LZRD |
|
Flag |
Bulgaria |
|
Port of registry |
Bourgas |
|
GT |
94 t |
|
NT |
28 t |
|
Length |
20,00 m overall 17,10 m between perpendiculars |
|
Breadth |
6,35 m overall |
|
Draught |
Max.: 2,40 m |
|
Air draft |
Min.: 5,40 m |
|
Depth |
2,96 m |
|
Speed |
12,0 knots |
|
Built |
2001 |
|
Builder |
Makedonia Shipyard Thessaloniki Greece |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Continuous decks |
1 |
|
Main engine |
2x Mitsubishi S12A2 combustion engines each 1.100 hp at 2.200 rpm Built: 2013 |
|
Previous main engine |
1x MTU - 4 stroke 12 cylinder combustion engine 1.490 kW / 2.024 hp at 1.500 rpm Builder: Mercedes |
|
Propellers |
2x Fixed pitch propellers diameter 1.500 mm |
|
Generators |
1x SW diesel generatorset 65 kW / 81 kVA- 220/380 Volt, 50 Hz 1x John Deere generatorset 38 kW / 48 kVA- 220/380 Volt, 50 Hz |
|
Bollard pull |
30 t |
|
Fi-Fi system |
Type: Separate engine driven pump capacity: 2x 310 m³/h Foam capacity: 3,2 m³ |
|
Tank capacities |
Fuel oil: 13,6 m³ Fresh water: 5 m³ |
|
Anchor equipment |
2x 200 kg Chain: 100 m diameter: 13 mm |
|
Accommodation |
2-Men cabins: Two Messroom: One |
|
Manager |
Multraship Towage & Salvage Scheldekaai 48 4530 AB Terneuzen The Netherlands |
|
Registered owner |
Multratug Bourgas BV Bulgaria |
|
Lastest data adjustment |
23 April 2021 |
