SD Rebel - IMO 9600774

Spijkenisse, The Netherlands 09 July 2021

Name

SD REBEL

Type

Tug - Azimuth stern drive

Type Damen ASD Tug 2810

IMO-number

9600774

Call sign

9HA3067

Flag

Malta

Port of registry

Valletta

Previous flags

2012 - 2012 Saint Vincent and the Grenadines - Call sign: J8B4681

GT

294 t

DWT

217 t

NT

88,00 m

Length

28,67 m overall

25,78 m between perpendiculars

Breadth

9,80 m

Draught

4,60 m

Max.: 4,80 m

Air draft

15,00 m

Depth

4,60 m moulded

Speed

11,8 knots

Built

2012

Keel laid

26/11/2010

Launch date

10/05/2011

Date of completion

28/03/2012

Builder casco

Santierul Naval Damen Galati S.A.

Romania

Yard Number: 1209

Builder completion

Damen Shipyard Gorinchem

Gorinchem

The Netherlands

Yard number: 511581

Hull material

Steel

Hull type

Single hull

Number of decks

1

Main engine

2x Caterpillar 3516 C - 16 cylinder combustion engines each 1.864 kW total 3.730 kW / 5.076 bhp at 1.600 rpm

Built: 2011

Manoeuvrability

2x Rolls Royce Aquamaster US 205 Fixed pitch propeller

Diameter: 2.400 mm

Generators

2x Caterpillar C 4.4 DITA diesel generatorsets each 107 kVA - 400 Volt 50 Hz

Bollard pull

Bollard pull ahead: 60;0 ton

Bollard pull astern: 58;3 ton

Deck layout

• Anchors: 2x 360 kg Pool (high holding power)

• Anchors/towing winch: Hydraulically driven two speed winch with split drum and warping head, pull 35 ton at 9,2 m/min and slack rope up to 27 m/min, 150 ton brake

• Capstan: 5 ton at 15 m/min, electrically driven

• Towing hook aft: Mampaey SWL 650 kN/65 ton

• Fendering: D-fender at sides, cylinder fender at transom corners, cylinder and W block bow fender

Towing equipment

Anchor / Towing winch:

1x Split drum, on drum 160,00 m Diameter 76 mm Ultraline

Firefighting

Diesel driven pump Caterpillar type C32 ACERT - 2.400 m³/h

FIFI monitor:

2x 1.200 m³/h, water

2x 300 m³/h, foam

Tank capacities

Fuel oil: 85,30 m³

Fresh water: 14,90 m³

Ballast water: 15,70 t

Sewage: 2,20 m³

Dirty oil: 3,10 m³

Lub oil: 9,00 m³

Bilge water: 5,10 m³

Sludge: 3,10 m³

Foam: 6,50 m³

Lifting equipment

1x Hydraulic crane Heila HLM 20-2S - SWL 2,2 t at 8,60 m

Crew size

6

Accommodation

2x Single cabins

2x Double cabins

Galley, mess/dayroom, dry store & sanitary facilities

Communication navigation

GMDSS A1

Radar

Autopilot

Magnetic compass

GPS

2x VHF DSC

2x VHF Handheld

Navtex

Epirb

Sart

Ais

GSM Mobile phone

Speedlog

Echo sounder

Registered owner

BOLUDA Corporation Maritima

Valencia

Spain

Previous owners

2011 - 2016 SD Rebel Ltd.,Valletta - Malta

2016 - 2019 Kotug Smit Towage, Rotterdam - The Netherlands

Latest data adjustment

06 March 2022
