Merksem, Belgium 20 July 2017 |
 |
| Merksem 20/07/17 |
|
Name |
LIBRA |
|
Type |
Tug - pusher |
|
ENI-number |
02332645 |
|
Call sign |
PB3902 |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
Tonnage |
91 t |
|
Length |
32,00 m |
|
Breadth |
11,00 m |
|
Draught |
2,17 m |
|
Viewing height |
12,00 m |
|
Air draft |
5,80 m |
|
Built |
2009 |
|
Builder |
Tinnemans Sheepsbouw B.V. |
|
Yard number |
1067 |
|
Hull material |
Steel |
|
Main engine |
2x Caterpillar 3512 (C) DI-TA electronic each 1.350 kW / 1.836 hp at 1.600 rpm |
|
Gearbox |
2x Disc reductions type MGX 5600, “Quick Shift” - reduction 5,04:1 |
|
Propellers |
2x 4 Blades propeller - diameter: 2.000 mm with 2 nozzle type Giessen Optima diameter: 2.012 mm |
|
Generators |
2x Generatorsets John Deere 150 KVA each |
|
Bow thruster |
1x DAF Ballegooy - 510 hp |
|
Owner |
Rederij De Jong BV The Netherlands |
|
Latest data adjustment |
15 August 2017 |
