| Westerschelde 15 August 2016 |
 |
 |
 |
 |
|||
| Westerschelde 05/08/09 | Westerschelde 05/08/09 | Westerschelde 05/06/14 | Westerschelde 11/12/16 | |||
|
Name |
GRANDE COLONIA |
|
Type |
Roll-On/Roll-Off vehicles carrier |
|
IMO-number |
9318527 |
|
Call sign |
IBXR |
|
Flag |
Italy |
|
Port of registry |
Palermo |
|
GT |
38.651 t |
|
DWT |
12.292 t |
|
NT |
13.843 t |
|
Displacement |
24.892 t |
|
Length |
176,00 m overall 165,00 m between perpendiculars 167,52 m registered |
|
Breadth |
31,13 m overall |
|
Draught |
Summer: 8,76 m |
|
Lanemetres |
3.1000 m |
|
Freeboard |
5.726 mm |
|
Depth |
14,46 m |
|
Speed |
20,5 knots |
|
Built |
2007 |
|
Keel laid |
09/02/2007 |
|
Launch date |
21/07/2007 |
|
Date of completion |
16/10/2007 |
|
Builder |
Uljanik Shipbuilding Industries Pula Croatia |
|
Yard number |
470 |
|
Hull material |
Ordinary steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W 7S50MC-C - 2 stroke 7 cylinder 500 x 2.000 mm combustion engine 11.060 kW / 13.960 bhp |
|
Propellers |
1x Controllable pitch propeller |
|
Number of cars |
4.632 |
|
Number of complete decks |
8 |
|
Number of partial decks |
3 |
|
Number of passengers |
12 |
|
Crew |
26 |
|
Manager |
Grimaldi Deep Sea S.P.A. |
|
Operator |
Grimaldi Lines Grimaldi Group 13, Via Marchese Campodisola Napoli Italy |
|
Registered owner |
Inarme 13, Via Marchese Campodisola Napoli Italy |
|
Owner as completed |
Industria Armamento Meridionale SpA. |
|
Latest data adjustment |
31 October 2024 |
