| Antwerpen 25 May 2015 |
 |
 |
|
| Antwerpen 25/05/15 | Zeebrugge 27/05/12 |
|
Name |
MORNING CARA |
|
Type |
Vehicles carrier |
|
Classification |
Nippon Kaiji Kyokai Register of Shipping |
|
IMO-number |
9574092 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
59.454 t |
|
DWT |
18.907 t |
|
NT |
19.152 t |
|
Length |
199,97 m |
|
Breadth |
32,26 m |
|
Draught |
Summer: 10,017 m |
|
Moulded L x B x D |
192.,0 x 32,26 x 14,70 m |
|
Registered L x B x D |
194,14 x 32,26 x,21.31 m |
|
Freeboard |
Summer: 4.714 mm |
|
Depth |
14,70 m moulded |
|
Keel laid |
27.05.2010 |
|
Launch date |
16.12.2010 |
|
Date of completion |
30.05.2011 |
|
Builder |
Imabari Shipbuilding Co., Ltd. Marugame Headquarters |
|
Yard number |
1531 |
|
Hull material |
Steel |
|
Main engine |
1x 2 stroke single acting 8 cylinder diesel 600 x 2.300 mm diesel engine - 13.260 kW at 100,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller |
1 |
|
Propeller shaft |
1x oil lubrication shaft with monitoring device |
|
Boilers |
1x Auxiliary vertical boiler - 8,0 bar Evaporation: 4,04 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Main diesel generatorsets each 4.275 kVA |
|
Car capacity |
6.215 |
|
Tank capacities |
Fuel oil: 2.815 m³ Fresh water: 659 m³ Water ballast: 9.327 m³ |
|
Lifting capacity |
2x Cranes - SWL 0,5 t each 3x Cranes - SWL 4,0 t each |
|
Crew |
23 |
|
Manager |
World Marine Co., Ltd. |
|
Operator |
EUKOR |
|
Registered owner |
Vertex Shipholding S.A. |
