| Zeebrugge 22 May 2009 |
 |
 |
 |
 |
|||
| Zeebrugge 22/05/09 | Zeebrugge 21/05/09 | Zeebrugge 21/05/09 | Westerschelde 21/05/14 | |||
|
Name |
MORNING CHARLOTTE |
|
Korean name |
모닝 샬롯 |
|
Type |
Roll-On/Roll-Off carrier - Vehicles carrier PCC - Pure Car Carrier |
|
IMO-number |
9338694 |
|
Call sign |
3E2746 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
61.002 t |
|
DWT |
22.362 t |
|
NT |
18.301 t |
|
Length |
199,94 m overall 190,00 m between perpendiculars |
|
Breadth |
32,26 m over all |
|
Draught |
Summer: 10,01 m |
|
Moulded L x B x D |
190,00 x 32,26 x 15,00 m |
|
Registered L x B x D |
194,11 x 32,26 x 24,32 m |
|
Freeboard |
Summer: 5.025 mm |
|
Depth |
24,32 m |
|
Speed |
Trial: 22,1 knots Service: 20,0 knots |
|
Built |
2007 |
|
Keel laid |
04/12/2006 |
|
Launch date |
19/06/2007 |
|
Date of completion |
31/08/2007 |
|
Builder |
Imabari Zosen Shipbuilding Co., Ltd. (Marugame Headquarters) Marugame Japan |
|
|
S-1464 |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsubishi 8UEC 60LSII - 2 stroke single acting 8 cylinder 600 x 2.300 mm combustion engine 15.540 kW / 21.128 bhp at 104 rpm Build: 01/09/2007 Manufacturer: Kobe Diesel Co., Ltd. |
|
Number of screws |
1 |
|
Boiler |
1x Auxiliary vertical boiler - 7,8 bar Evaporation: 4,35 t/h Heating surfuce: 37,0 m² Economizer EGE - 10,8 kg/cm² Heating surfuce: 425,7 m² Manufacturer: Miura Protec Co., Ltd. |
|
Generators |
3x main diesel generatorsdets each 1.250 kVA / 450 Volt |
|
Tank capacities |
Fuel oil: 3.512,6 m³ Freshwater: 413,6 m³ Water ballast: 10.066,2 m³ |
|
Cargo capacity |
Cars: 6.502 Trucks: 162 |
|
Lifting equipment |
2x Cranes - SWL 0,9 t each 3x Cranes - SWL 4,0 t each |
|
Crew |
20 |
|
ISM & commercial manager |
Wilhelmsen Ship Management (Korea) Ltd. |
|
Previous manager |
Excel Marine Co. Ltd., Fukuoka - Japan |
|
Registered owner |
Charlotte International Maritime S.A. |
|
Previous owner |
Jek. Navigation (Panama) S.A., Panama City - Republic of Panama |
|
Latest data adjustment |
14 April 2023 |
