Westerschelde 26 October 2018 |
Westerschelde 26/10/18 | Westerschelde 01/08/19 | |
Name |
GLOVIS SPLENDOR |
Korean name |
글로비스 스플렌더 |
Location |
Roll-On/Roll-Off carrier - Vehicles carrier |
IMO-number |
9702431 |
Call sign |
South Korea |
Flag |
D7GY |
Port of registry |
Jeju |
Previous flag |
2014 - 12/2022 Marshall Islands, Majuro - Call sign: V7IM3 |
GT |
64.546 t |
DWT |
20.056 t |
NT |
22.577 t |
Length |
199,97 m overall |
Breadth |
35,40 m |
Draught |
Max: 10,02 m |
Reg. dimensions L x B x D |
194,32 x 35,40 x 20,52 m |
Rule dimensions L x B x D |
188,80 x 35,40 x 14,48 m |
Freeboard |
Summer: 3.220 mm |
Depth |
20,52 m registered |
Speed |
Max: 19,9 knots |
Built |
2014 |
Keel laid |
21/05/2014 |
Launch date |
27/07/2014 |
Date of completion |
28/10/2014 |
Builder |
Hyundai Samho Heavy Industries Co., Ltd. Yeonga South Korea |
Yard number |
S-720 |
Hull material |
Steel |
Main engine |
1x MAN-B&W/HHI 7S60ME-C8 - 2 stroke single acting 7 cylinder 600 x 2.400 mm combustion engine 13.070 kW / 17.770 hp at 102,0 rpm Build: 05/2014 Builder: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division - South Korea |
Propellers |
1x Fixed pitch propeller |
Boilers |
1x Auxiliary Boiler CPB - 8,8 bar Heating surface: 30,2 m² 2x Economizer EGE - 12,7 bar Heating surface: 483,0 m² Build: 04/2014 Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
Generators |
1x Generator 1.250 kVA - 450 volt 2x Generator each 1.875 kVA - 450 volt |
Number of cars |
7.280 |
Number of ramps |
2 |
Tank capacities |
Fuel oil: 3.452,2 m³ Fresh water: 320,7 m³ Water ballast: 9.230,8 m³ |
Commercial manager |
Hyundai Glovis Co., Ltd. 512, Yeongdong-daero, Gangnam-gu Seoul, 06172 South Korea |
ISM manager |
G-Marine Service Co., Ltd. 331, Jungang-daero, Dong-gu Busan, 48792 South Korea |
Registered owner |
GL NV12 Shipping Inc. Care of Hyundai Glovis Co Ltd. 512, Yeongdong-daero, Gangnam-gu Seoul, 06172 South Korea |
Latest data adjustment |
29 January 2023 |
