Westerschelde 26 June 2019 |
 |
 |
|
| Westerschelde 22/05/19 | Westerschelde 18/04/18 | |
|
Name |
HANNAH SCHULTE |
|
Previous names |
2006 Launch as: Hannah Schulte 10/2006 - 02/2015 Maersk Needham |
|
Type |
Cellular containership - Feedermax |
|
IMO-number |
9301938 |
|
Call sign |
9VEZ2 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
26.671 t |
|
DWT |
Summer: 34.704 t |
|
NT |
12.679 t |
|
Number of 20ft containers |
On deck: 1.524 In hold: 1.078 Total: 2002 |
|
Container capacity 14t |
1.854 |
|
Reefer capacity |
600 |
|
Length |
210,00 m overall |
|
Breadth |
30,10 m |
|
Draught |
Summer: 11,52 m |
|
Reg. dimensions L x B x D |
200,35 x 30,10 x 16,70 m |
|
Rule dimensions L x B x D |
198,80 x 30,10 x 16,70 m |
|
Keel to mast end |
51,98 m |
|
Freeboard |
Summer: 5.140 mm |
|
Depth |
16,70 m |
|
Speed |
Max: 23,3 knots Service: 22,1 knots |
|
Built |
2006 |
|
Keel laid |
29/05/2006 |
|
Launch date |
31/07/2006 |
|
Date of completion |
19/10/2006 |
|
Builder |
STX Offshore & Shipbuilding Co., Ltd. Changwon (Jinhae Shipyard) South Korea |
|
Yard number |
1181 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 8S70MC-C - 2 stroke single acting 8 cylinder 700 x 2.800 mm combustion engine Mcr 24.841 kW / 33.774 hp at 91,0 rpm Build: 04/2006 Builder: STX Engine Co., Ltd., Changwon - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 91,0 rpm |
|
Boilers |
1x Auxiliary boiler CPB Pressure: 6,9 kg/cm² Heating surface: 476 m³ Build: 05/2006 Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
4x MAN-B&W 8L28/32H - 8 cylinder diesel engines each 1.700 kW connected with generators each 1.600 kW - 450 Volt |
|
Bow thruster |
1x Tunnel thruster 1.000 kW / 1.360 bhp, forward |
|
Tank capacities |
Fuel oil: 4.005,9 m³ Diesel oil: 130 m³ Fresh water: 274,2 m³ Water ballast: 9.466,0 m³ |
|
Cargo gear |
4x Deck cranes - SWL 45,0 t each |
|
Crew size |
18 |
|
Commercial manager |
Hanseatic Unity Chartering HU Zirkusweg 3 20359 Hamburg Germany |
|
ISM manager |
Bernhard Schulte Shipmanagement (Hellas) SPLLC 6-8, Kifisias Avenue Marousi, 151 25 Athens Greece |
|
Registered owner |
Fort Park Shipping Co., Pte Ltd. - Republic of Singapore Care of Hanseatic Unity Chartering (HU) GmbH & Co., KG Zirkusweg 3 20359 Hamburg Germany |
|
Latest data adjustment |
22 February 2022 |
.
