Westerschelde 28 April 2017 |
WS 28/04/17 | |
Name |
DOMINGO |
Previous names |
2001 - 2012 Cap San Marco 2012 - 2016 Cap Domingo |
Type |
Cellular containership - Panamax |
IMO-number |
9215672 |
Call sign |
V7XV5 |
Flag |
Marshall Islands |
Port of registry |
Majuro |
Previous flags |
2001 - 2001 Germany 2001 - 2012 Liberia, Monrovia - Call sign ELZA9 |
GT |
40.087 t |
DWT |
51.087 t |
NT |
24.319 t |
Number of 20ft containers |
3.739 |
Container capacity 14t |
2.800 |
Reefer capacity |
800 |
Length |
257,33 m overall 245,56 m between perpendiculars |
Breadth |
32,20 m |
Draught |
Summer: 12,53 m |
Depth |
19,30 m |
Freeboard |
3.101 mm |
Speed |
Max: 22,5 knots |
Built |
2001 |
Keel laid |
11/10/2000 |
Launch date |
16/01/2001 |
Date of completion |
20/03/2001 |
Builder |
Samsung Heavy Industries Co., Ltd. Geoje South Korea |
Yard number |
1330 |
Hull material |
Steel |
Watertight bulkheads |
10 |
Continuous decks |
1 |
Main engine |
1x Sulzer 7RTA84C - 2 stroke 7 cylinder 840 x 2.400 mm combustion engine Mcr 28.350 kW / 38.545 hp at 102,0 rpm Build: 02/2000 Manufacturer: Samsung Heavy Industries Co., Ltd. |
Propellers |
1x Screw propeller solid - aft at 102,0 rpm |
Boilers |
1x Composite boiler - 9,0 bar Heating surface: 75 m² / 469 m² Manufacturer: Parat Anders Halvorsen AS, Flekkefjord |
Electric installations |
1x Plant 440/ 220 V - 2.250 kVA 1x Plant 440/ 220 V - 2.250 kVA 1x Plant 440/ 220 V - 2.250 kVA 1x Plant 440/ 220 V - 2.250 kVA 1x Plant 440 V - 188 kVA 1x Plant 24 V - 200 Ah 1x Plant 24 V - 400 Ah |
Generators |
4x Main diesel generatorsets each 2.250 kVA - 1.800 kW - 2.568 hp |
Emergency generator |
1x Diesel generatorset 188 kVA - 150 kW - 255 hp |
Compressed air receivers |
2x Receivers each 6.900 litres - 31,0 bar 1x Receiver 300 litres - 9,0 bar 1x Receiver 100 litres - 7,7 bar |
Bow thruster |
1x Nakashima - 1.300 kW, forward |
Number of holds |
7 |
Cargo hold capacity |
60.200 m³ |
Tank capacities |
Fuel: 6.662,8 m³ Ballast water: 14.146 m³ |
Anchor equipment |
3x Anchors weight each 11.700 kg Chain Length: 687,50 m |
Cargo gear |
2x Cargo deck cranes - SWL 45,0 t each |
Crew size |
27 |
Owner |
Diana Containerships Inc. |
Renamed |
08/2020 MSC Jessenia R Liberia, Monrovia - Call sign: D5YE2 Owner: Jessenia Shipping Ltd. - Care of MSC Shipmanagement Ltd., Limassol - Cyprus Manager: MSC Shipmanagement Ltd., Limassol - Cyprus |
Latest data adjustment |
25 February 2024 |
