| Antwerpen 15 January 2009 |
|
Name |
DOERTE |
|
Previous names |
1994-1999 Dörte |
|
Type |
Containership |
|
IMO-number |
9100061 |
|
Call sign |
V2CG |
|
Flag |
Antigua & Barbuda |
|
Previous flag |
1994 Germany |
|
Port of registry |
St. John's |
|
GT |
3.957 t |
|
DWT |
5.388 t |
|
NT |
2.080 t |
|
Number of 20ft containers |
448 |
|
Reefer capacity |
36 |
|
Length |
107,98 m overall |
|
Breadth |
16,40 m overall |
|
Draught |
Summer: 6,00 m |
|
Freeboard |
1.870 mm |
|
Depth |
7,05 m |
|
Speed |
15,2 knots |
|
Freeboard |
Summer: 1.870 mm |
|
Built |
1994 |
|
Builder |
Detlef Hegemann Rolandwerft GmbH & Co. KG, |
|
Yard number |
171 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
8 |
|
Continuous decks |
2 |
|
Main engine |
1x Deutz MWM TBD645L9 - 9 cylinder 350 x 330 mm diesel engine - 3.690 kW / 5.014 hp at 600 rpm |
|
Propelling system |
1x Screw propeller controllable pitch at 168 rpm |
|
Electrical installation |
Power voltage: 380 V |
|
Shaft generator |
1x 600 kW |
|
Diesel generators |
2x Main diesel generatorsets each 310 kVA - 248 kW - 361 hp |
|
Emergency generators |
1x Diesel generatorset 98 kVA - 78 kW - 111 hp |
|
Cargo holds |
2 |
|
Bunker capacity |
321 t |
|
Cargo gear |
Gearless |
|
Manager |
Kapitän Manfred Draxl Schiffahrts GmbH & Co. KG MS "DÖRTE" |
|
Owner |
Kapitan Manfred Draxl |
