Westerschelde 04 May 2016 |
 |
|
| Westerschelde 13/04/15 | |
|
Name |
MSC ALTAIR |
|
Previous names |
2012 Launch as: E.R. Altair |
|
Type |
Cellular containership |
|
IMO-number |
9465277 |
|
Call sign |
A8YN2 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
141.635 t |
|
DWT |
Summer: 141.051 t |
|
NT |
63.825 t |
|
Number of 20ft containers |
On deck: 7.074 In hold: 6.028 Total: 13.102 |
|
Container capacity 14t |
9.178 |
|
Reefer capacity |
800 |
|
Length |
366,36 m overall 349,96 m between perpendiculars |
|
Breadth |
48,26 m extreme |
|
Draught |
15,50 m |
|
Depth |
29,85 m |
|
Speed |
Max.: 24,7 knots |
|
Built |
2012 |
|
Keel laid |
15/09/2011 |
|
Launch date |
09/12/2011 |
|
Date of completion |
01/03/2012 |
|
Builder |
Hyundai Heavy Ind. Co., Ltd. 1, Cheonha-dong, Dong-gu Ulsan, 682-792 Kyongsang-namdo Republic of Korea |
|
Yard number |
2157 |
|
Hull material |
Shipbuilding steel (standard) - Partly made of higher tensile steel |
|
Hull type |
Partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkhead |
11 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 12K98ME - 2 stroke 12 cylinder 980 x 2.660 mm combuistion engine 72.240 kW / 98.218 hp at 97,0 rpm Manufacturer: Hyundai Heavy Industries Co., Ltd. 1, Jeonha-dong, Dong-gu Ulsan ,682-792 Kyongsang-namdo Republic of Korea |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Steam boiler, oil fired - 7,85 bar Heating surface: 73,4 m² 1x Steam boiler, exhaust gas heated - 9,81 bat Heating surface: 911,4 m² Year of manufacture: 2011 Manufacturer: KangRim Heavy Industries Co., Ltd. 40, Wongnam-dong Changwon ,642-290 Kyongsang-namdo Republic of Korea |
|
Electric installations |
4x Plants each 6.600 V with 4.426,7 kVA 1x Plant 450 V - 370 kVA 2x Plants each 12 V - 3 Ah 2x Plants each 24 V - 200 Ah 12x Plants each 24 V - 200 Ah 12x Plants each 24 V - 200 Ah |
|
Generators |
4x Hyundia/Himsen 7H32/40 diesel generatorsets each 3.540 kW / 4.426,7 kVA |
|
Emergency generator |
1x Scania DC123 54A diesel generatorset 370 kVA |
|
Batteries |
12x Batteries for UPS navigation each 200 Ah 12x Batteries for UPS radio each 200 Ah 2x Batteries for start emergency engine each 200 Ah 2x Batteries for Other purpose each 3 Ah |
|
Compressed air receivers |
2x Receivers each 16.000 litres - 32,4 bar 1x Receiver 500 litres - 32,4 bar 1x Receiver 300 litres - 7,7 bar 1x Receiver 2.000 litres - 7,56 bar |
|
Bow thruster |
2x Transverse thruster each 1.800 kW, forward |
|
Number of holds |
10 |
|
Tank capacities |
Ballast: 37.456,7 m³ |
|
Anchor equipment |
3x Anchors weight each 24.500 kg Length: 770,00 m Diameter: 122 mm |
|
Cargo gear |
Gearless |
|
Crew size |
28 |
|
ISM & commercial manager |
MSC Shipmanagement Limited MSC House, 8, Spyrou Kyprianou Avenue Limassol Cyprus |
|
Registered owner |
CL Jupiter Ltd. 21st Floor, Edinburgh Tower, The Landmark, 15, Queen's Road Central Hong Kong - China |
|
Previous owner |
Sinoceanic II AS |
|
Latest data adjustment |
17 November 2023 |
