Westerschelde 04 October 2019 |
 |
 |
 |
 |
|||
| Terneuzen 11/07/19 | Terneuzen 11/07/19 | Westerschelde 09/01/20 | Westerschelde 24/06/20 | |||
|
Name |
MSC ALICANTE |
|
Previous names |
2011 - 2011 CPO Alicante |
|
Type |
Cellular containership |
|
IMO-number |
9480174 |
|
Call sign |
9HA5884 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
Liberia, Monrovia - Call sign: A8YN7 |
|
GT |
61.870 t |
|
DWT |
Summer: 74.477,24 t |
|
NT |
35.409 t |
|
Number of 20ft containers |
5.568 |
|
Container capacity 14t |
4.400 |
|
Reefer capacity |
716 |
|
Length |
270,33 m overall 257,50 m between perpendiculars |
|
Breadth |
40,05 m extreme |
|
Draught |
Max: 13,50 m |
|
Depth |
21,70 m |
|
Speed |
Max: 22,4 knots |
|
Built |
2011 |
|
Keel laid |
29/06/2010 |
|
Launch date |
30/12/2010 |
|
Date of completion |
10/06/2011 |
|
Builder |
Daewoo Mangalia Heavy Industries S.A. Mangalia Romania |
|
Yard number |
4082 |
|
Hull material |
Material Shipbuilding steel (standard) |
|
Hull type |
Double bottom Type partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
8 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 7K98MC-C - 2 stroke 7 cylinder 980 x 2.400 mm combustion engine 42.140 kW at 104,0 rpm Manufacturer: Doosan Engine Co., Ltd. |
|
Propellers |
1x Solid propeller (keyless) - aft at 104 rpm |
|
Boilers |
1x Steam boiler, oil fired / exhaust gas heated - 9,0 bar Heating surface: 29,5 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 471,0 m² Manufacturer: Alfa Laval Aalborg A/S |
|
Electric installations |
1x Plant 450 V - 2.867 kVA 1x Plant 450 V - 2.867 kVA 1x Plant 450 V - 3.333 kVA 1x Plant 450 V - 3.333 kVA 1x Plant 450 V - 438 kVA 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 300 Ah |
|
Shaft generator |
2x MAN 8L27/38 main diesel generatorsets each 2.500 kW / 3.333 kVA 2x MAN 7L27/38 main diesel generatorsets each 2.150 kW / 2.967 kVA |
|
Emergency generator |
1x KTA-19 DM diesel generatorset 438 kVA |
|
Batteries |
1x Battery for UPS navigation 300 Ah 1x Battery for UPS radio 200 Ah 1x Battery for start emergency engine 200 Ah |
|
Compressed air receivers |
2x Receivers each 13.500 litres - 33,0 bar 1x Receiver 400 litres - 33,0 bar 1x Receiver 2.000 litres - 7,7 bar 1x Receiver 250 litres - 7,7 bar |
|
Bow thruster |
1x Transverse thruster 2.000 kW, forward |
|
Tank capacities |
Ballast: 23.251 m³ |
|
Anchor equipment |
3x Anchors weight each 16.100 kg Length: 751,00 m Diameter: 97 mm |
|
Cargo gear |
Gearless |
|
ISM manager |
Claus-Peter Offen Containerschiffreederei (GmbH & Co.) KG Bleichenbruecke 10 20354 Hamburg Germany |
|
Commerical manager |
Claus-Peter Offen Containerschiffreederei GmbH & Co. Bleichenbruecke 10 20354 Hamburg Germany |
|
Operator |
MSC - Mediterranean Shipping Company |
|
Registered owner |
Kommanditgesellschaft MS "CPO ALICANTE" Offen Reederei GmbH & Co. Care of Reederei Claus-Peter Offen GmbH & Co K Bleichenbruecke 10 20354 Hamburg Germany |
|
Latest data adjustment |
05 April 2024 |
