| Westerschelde 29 September 2012 |
 |
| Westerschelde 03/08/14 |
|
Name |
CMA CGM VERDI |
|
Type |
Cellular containership |
|
IMO-number |
9280653 |
|
Call sign |
C6TH7 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
65.247 t Suez: 67.792 t |
|
DWT |
73.235 t |
|
NT |
37.549 t Suez: 56.516 t |
|
Number of 20ft containers |
5.782 |
|
Container capacity 14t |
4.390 |
|
Reefer points |
500 |
|
Length |
277,28 m overall 260,06 m between perpendiculars |
|
Breadth |
40,00 m |
|
Draught |
14,50 m |
|
Freeboard |
6.662 mm |
|
Depth |
24,30 m |
|
Speed |
24,5 knots |
|
Service |
Europe Pakistan India Consortium |
|
Built |
2004 |
|
Date of completion |
05.10.2004 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje Shipyard |
|
Yard number |
1463 |
|
Hull material |
Steel |
|
Watertight compartments |
12 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN B&W 10K98MC-C - 2 stroke 10 cylinder 980 x 2.400 mm diesel engine - 57.114 kW / 77.600 hp at 104,0 rpm Build: 2004 Builder: Hyundai Heavy Industries Co., Ltd., Ulsan - South Korea |
|
Propellers |
1x Screw propeller solid at 104 rpm |
|
Boilers |
1x CHO Aalborg 41,40 m² - 9,0 bar |
|
Electric installation |
Power voltage: 440 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Shaft generator |
1x 2.100 kW / 2.625 kVA |
|
Generators |
3x Main diesel generatorsets each 3.375 kVA - 2.700 kW - 3.861 hp |
|
Emergency generator |
1x Diesel generatorset 188 kVA - 150 kW - 270 hp |
|
Number of holds |
8 |
|
Number of hatches |
8 1x Hatch: 12,60 x 15,50 m 1x Hatch: 12,60 x 30,60 m 6x Hatches: 12,60 x 35,70 m |
|
Fuel capacity |
9.092 m³ |
|
Lifting equipment |
2x Cranes - SWL 12,5 t each |
|
Handling gear |
None |
|
Manager |
Technomar Shipping Inc. |
|
Operator |
CMA CGM - Compagnie Maritime D'Affrètement - Compagnie Générale Maritime |
|
Owner |
A & L CF September (3) Limited |
|
Registered owner |
Verdi Marine LLC |
