CMA CGM Verlaine - IMO 9221815

Name

CMA CGM VERLAINE

Previous name

2001 Buld as: Buxcliff

Type

Cellular Containership

IMO-number

9221815

Call sign

DASO

Flag

Germany

Previous flags

2001 Republic of Panama
2002 Republic of Liberia

Port of registry

Hamburg

GT

72.760 t

Summer DWT

77.900 t

NT

41.077 t

Number of 20ft containers

In hold: 3.058
On deck: 3.654
Total: 6.712

Container capacity 14t

4.995

Reefer Point

500 on deck up to 3rd tier

Length

300,40 m overall
286,00 m between perpendiculars
289,06 m registered

Breadth

40,00 m over all

Draught

Summer: 14,52 m

Freeboard

9.700 mm

Depth

24,10 m

Speed

Max.: 27,0 knots

Built

2001

Keel laid

22/01/2001

Launch Date

14/04/2001

Date of completion

06/2001

Builder

Daewoo Shipbuilding & Marine Engineering Co. Ltd.
Okpo
South Korea

Yard number

4070

Hull material

Shipbuilding steel (higher tensile)

Hull type

Single hull
Double bottom, continuous from peak to peak bulkhead

Watertight bulkheads

8

Continuous decks

1

Main engine

1x MAN-B&W 12K98MC-C - 2 stroke single acting 12 cylinder 980 x 2.400 mm combustion engine 68.520 kW / 93.160 hp at 104,0 rpm
Builder: Hyundai Heavy Industries, Ulsan- South Korea

Number of screws

1x Solid propeller (keyless) - aft at 104,0 rpm

Boilers

1x Steam boiler, oil fired - 7,0 bar
Heating Surface: 137,8 m²
1x Steam boiler, exhaust gas heated - 9,8 bar
Heating surface: 744,5 m²
Year of manufacture: 2001
Manufacturer: KangRim Ind. Co., Ltd. (1st Factory)

Electric installations

1x 440/220 V - 10.500 kVA
1x 440 V - 688 kVA
1x 24 V - 6.000 Ah

Generators

3x Wärtsilä 8R32 - 4 stroke 8 cylinder 320 x 350 diesel engine each 2.960 kW connected with generator each 2.800 ekW

Emergency generator

1x Diesel generatorset 688 kVA

Bow thruster

1x Variable pitch propeller LIPS - 1.500 kW forward

Anchor equipment

3x Anchors weight each: 16.100 kg
Chain length: 742,50 m

Tank capacities

Ballast: 19.301 m³

Compressed air receivers

2x Receivers each 22.000 litres - 30,0 bar
1x Receiver 200 litres - 30,0 bar
1x Receiver 125 litres - 30,0 bar

Cargo gear

Gearless

Operator

CMA CGM

Manager

NSB Niederelbe Schiffahrts GmbH & Co. KG.
Harburger Str. 47-51
21614 Buxtehude
Federal Republic of Germany

Owner

Bereederungs- und Schiffahrtsges. mbH & Co. MS "BUXCLIFF" KG
Harburger Str. 4
21614 Buxtehude
Federal Republic of Germany

Renamed

2013 Buxcliff
Germany, Hamburg - Call sign: SASO

Latest data adjustment

05 October 2020
