Name |
KATHERINE |
|
Previous names |
2013 - 05/2014 Katherine 05/2014 - 2017 Safmarine Highveld 2017 - 2017 JB Herine |
|
Type |
Cellular containership - Post-Panamax |
|
IMO-number |
9641235 |
|
Call sign |
V7ZU2 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
Republic of Panama |
|
GT |
71.021 t |
|
DWT |
Summer: 80.295 t |
|
NT |
40.452 t |
|
Displacement |
103.698 t |
|
Number of 20ft containers |
6.881 |
|
Container capacity 14t |
4.950 |
|
Reefer capacity |
900 |
|
Length |
270,06 m overall 257,99 m between perpendiculars |
|
Breadth |
42,80 m moulded |
|
Draught |
Max: 14,50 m |
|
Depth |
24,80 m |
|
Speed |
Max: 22,5 knots |
|
Built |
2013 |
|
Keel laid |
10/12/2012 |
|
Delivery date |
30/04/2013 |
|
Builder |
Hyundai Samho Heavy Industries Co. Ltd. Samho South Korea |
|
Yard number |
S623 |
|
Hull material |
Steel - High resistance and ordinary |
|
Continuous decks |
1 |
|
Number of partial decks |
9 |
|
Main engine |
1x Wärtsilä 8RT-flex82T - 2 stroke single acting 8 cylinder 820 x 3.375 mm combustion engine Mcr 33.670 kW / 45.778 hp at 78,0 rpm Manufacturer: Hyundai Heavy Industries Co Ltd; Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 78,0 m |
|
Generators |
3x Hyundai-Himsen 7H32/40 - 4 stroke 7 cylinder 320 x 400 mm diesel engines each 3.500 kW coupled with generators each 3.150 kW / 6.600 Volt 1x Hyundai-Himsen 6H32/40 - 4 stroke 6 cylinder 320 x 400 mm diesel engines each 3.000 kW coupled with generators each 2.700 kW / 6.600 Volt Manufacturer: Hyundai Himsen |
|
Bow thruster |
1x Tunnel thruster 2.500 kW / 3.399 bhp |
|
Tank capacities |
Fuel oil: 7.180 m³ |
|
Cargo gear |
Gearless |
|
Crew size |
20 |
|
ISM manager |
Technomar Shipping Inc. 3-5, Menandrou Street Kifisia, 145 61 Athens Greece |
|
Commercial manager |
Conchart Commercial Inc. 3-5, Menandrou Street Kifisia, 145 61 Athens Greece |
|
Owner |
Ikaro Marine LLC Care of ConChart Commercial Inc. 3-5, Menandrou Street Kifisia, 145 61 Athens Greece |
|
Renamed |
07/2024 Costa Rica Express Marshall Islands, Majuro - Call sign: V7ZU2 registered owner: Ikaros Marine Llc Manager: Technomar Shipping Inc. |
|
Latest data adjustment |
12 November 2024 |
