Westerschelde 30 March 2018 |
 |
| Westerschelde 30/03/18 |
|
Name |
GOLBON |
|
Previous names |
2004 - 12/2008 Iran Ilam 12/2008 - 01/2011 Sepitam 01/2011 - 06/2012 Hadis |
|
Type |
Cellular containership |
|
IMO-number |
9283033 |
|
Call sign |
EPBL9 |
|
Flag |
Iran |
|
Port of registry |
Bandar Abbas |
|
Previous flags |
2004 - 2011 Iran 2011 - 2012 Barbados |
|
GT |
27.681 t |
|
DWT |
Summer: 37.894 t |
|
NT |
14.284 t |
|
Number of 20ft containers |
In hold: 992 On deck: 1.486 Total: 2.478 |
|
Container capacity 14t |
2.050 |
|
Reefer capacity |
200 |
|
Length |
221,62 m overall |
|
Breadth |
29,80 m |
|
Draught |
11,42 m |
|
Reg. dimensions L x B x D |
221,60 x 29,80 x 16,46 m |
|
Rule Dimensions L x B x D |
210,95 x 29,80 x 16,46 m |
|
Freeboard |
5.040 mm |
|
Depth |
16,46 m |
|
Speed |
Max: 22,3 knots |
|
Built |
2004 |
|
Keel laid |
09/12/2003 |
|
Launch date |
17/04/2004 |
|
Date of completion |
11/06/2004 |
|
Builder |
Aker MTW Werft GmbH |
|
Yard number |
24 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Single hull double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
8 |
|
Continuous decks |
2 |
|
Main engine |
1x Sulzer 7RTA72U-B - 2 stroke 7 cylinder 720 x 2.500 mm combustion engine 21.560 kW at 99,0 rpm Built: 01/2004 Manufacturer: Wärtsilä Italia S.p.A. |
|
Propellers |
1x Solid propeller (keyless)- aft at 99,0 rpm |
|
Boilers |
2x Steam boiler, oil fired / exhaust gas heated Max. allow. working pressure 9,0 bar Heating Surface: 36,5 m² Heating Surface: 310,0 m² Manufacturer: Siempelkamp Energie- und Anlagentechnik GmbH & Co. KG |
|
Electric installations |
1 Plant 440/220 V - 1.880 kVA 1 Plant 440/220 V - 1.880 kVA 1 Plant 440/220 V - 1.880 kVA 1 Plant 440 V - 220 kVA |
|
Generators |
2x Wärtsilä 9L20 main diesel generatorsets each 1.625 kVA - 450 Volt 1x Wärtsilä 6L20 main diesel generatorset 1.206 kVA - 450 Volt |
|
Emergency generator |
1x Emergency diesel generatorset 220 kVA |
|
Compressed air receivers |
2x Receivers each 9.000 litres, 30,0 bar |
|
Bow thruster |
1x Transverse thruster Kawasaki 1.620 kW |
|
Number of holds |
5 |
|
Tank capacities |
Fuel oil: 3.030,4 m³ Fresh water: 414,4 m³ Water ballast: 9.163,1 m³ |
|
Anchor equipment |
3x Anchors weight each 9.300 kg |
|
Cargo gear |
3x Deck cranes - SWL 45,0 t each |
|
Crew size |
25 |
|
Manager |
ROD - Rahbaran Omid Darya Ship Management Company |
|
Registered owner |
Oghiaanous Khoroushan Shipping Lines Co. Of Kish |
|
Latest data adjustment |
26 July 2018 |
