Westerschelde 28 August 2018 |
 |
 |
 |
 |
 |
||||
| Westerschelde 08/10/18 | Westerschelde 08/10/18 | Westerschelde 08/10/18 | Westerschelde 26/08/19 | Westerschelde 21/01/16 | ||||
|
Name |
MSC LUISA |
|
Type |
Cellular containership |
|
IMO-number |
9225677 |
|
Call sign |
H9XU7 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
75.590 t |
|
DWT |
Summer: 85.927 t |
|
NT |
42.233 t |
|
Number of 20ft containers |
6.750 |
|
Container capacity 14t |
5.150 |
|
Reefer capacity |
500 |
|
Length |
299,99 m overall 286,00 m between perpendiculars |
|
Breadth |
40,00 m extreme |
|
Draught |
Max: 14,50 m |
|
Depth |
24,20 m |
|
Speed |
Max: 25,4 knots |
|
Built |
2002 |
|
Keel laid |
04/10/2001 |
|
Launch date |
22/12/2001 |
|
Date of completion |
28/02/2002 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. Okpo Shipyard South Korea |
|
Yard number |
4077 |
|
Hull material |
Steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 10K98MC-C - 2 stroke 10 cylinder 980 x 2.400 mm combustion engine 57.100 kW at 104,0 rpm Build: 2001 Manufacturer: HSD Engine Co., Ltd. |
|
Propellers |
1x Solid propeller (keyless) - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,8 bar Heating surface 137,8 m² 1x Steam boiler, exhaust gas heated - 9,8 bar Heating surface 842,7 m² Build: 2001 Manufacturer: KangRim Heavy Industries Co., Ltd. (1st Factory) |
|
Electric installations |
1x Plant 440/ 220 V - 2.625 kVA 1x Plant 440/ 220 V - 2.625 kVA 1x Plant 440/ 220 V - 2.625 kVA 1x Plant 440/ 220 V -h 2.625 kVA 1x Plant 440 V - 688 kVA |
|
Generators |
4x Wärtsilä 6R32LND main diesel generatorsets each 2.625 kVA |
|
Emergency generator |
1x Caterpillar 3412 DIT diesel generatorset 688 kVA |
|
Compressed air receivers |
2x Receivers each 22.000 litres - 32,4 bar 1x Receiver 200 litres - 32,4 bar 1x Receiver 125 litres - 30,0 bar 1x Receiver 350 litres - 7,7 bar |
|
Bow thruster |
1x Variable pitch propeller LIPS - 2.000 kW, forward |
|
Tank capacities |
Ballast: 20.179,3 m³ Fuel: 10.854 m³ |
|
Anchor equipment |
3x Anchors weight each 16.900 kg Length: 752,50 m Diameter: 100 mm |
|
Manager |
Mediterranean Shipping Company S.r.l. |
|
Operator |
MSC - Mediterranean Shipping Co. |
|
Registered owner |
Gonte Investments Inc. |
|
Latest data adjustment |
12 March 2020 |
