Name |
GASCHEM BREMEN |
|
Type |
Liquefied gas tanker - LPG/NH3 carrier |
|
IMO-number |
9471032 |
|
Call sign |
D5WP6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2010 - 2017 Liberia, Monrovia 2017 - 2020 Germany, Leer - Call sign: DGLB2 |
|
GT |
22.977 t |
|
DWT |
Summer: 26.645 t |
|
NT |
6.893 t |
|
Length |
173,70 m overall 165,00 m between perpendiculars |
|
Breadth |
28,04 m moulded |
|
Draught |
10,31 m |
|
Keel - top antenna |
48,40 m |
|
Depth |
17,80 m moulded |
|
Speed |
Service: 16,5 knots laden |
|
Built |
2010 |
|
Delivery date |
18/10/2010 |
|
Builder |
Hyundai Mipo Dockyard Co. Ltd. Ulsan South Korea |
|
Yard number |
8066 |
|
Hull material |
Steel |
|
Hull type |
Double bottom |
|
Main engine |
1x Hyundai/MAN-B&W 6S50MC-C - 2 stroke 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW / 12.889 hp at 127,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Generators |
2x Hyundai/MAN 7L23/30H diesel generatorset each 960 kW 1x Hyundai/MAN 6L23/30H diesel generatorset 780 kW |
|
Number of cargo tanks |
3x Prismatic |
|
Cargo tanks capacity |
100 % / 98 % Tank 1: 9.770,97 / 9.575,55 m³ Tank 2: 14.767,38 / 14.472,04 m³ Tank 3: 10.694,11 / 10.480,23 m³ Deck tank1: 100,05 / 98,05 m³ Deck tank 2: 241,16 / 236,34 m³ Total: 35.232,46 / 34.527,81 m³ |
|
Number of deck tanks |
2 |
|
Pumps |
6x Hamworthy Deepwell cargo pumps each 400 m³/h 2x Booster pumps each 400 m³/h |
|
Max. tank pressure |
0,25 bar |
|
Min. design temperature |
-50°C |
|
Tank capacities |
IFO: 1.591 (95%) MGO: 131 (95%) Fresh water: 298 m³ Ballast: 11.392 m³ |
|
Lifting equipment |
1x Haean crane - SWL 5,0 t Manufacturer: Haean Machinery Ind. Co. |
|
Crew complement |
30 |
|
Navigation & communication equipment |
|
|
ISM manager |
Hartmann Gas Carriers Germany GmbH & Co. KG Koenigstrasse 23 26789 Leer Germany |
|
Commerical manager |
Stealthgas Inc. Building 2, Apollon Business Centre, 331, Kifisias Avenue, Kifisia 145 61 Athens Greece |
|
Registered owner |
Celsius Technologies Inc. Building 2, Apollon Business Centre, 331, Kifisias Avenue, Kifisia 145 61 Athens Greece |
|
Group |
Hartmann group |
|
Latest data adjustment |
03 September 2021 |
