Luna 03

Zeebrugge 24 March 2018


Luna 01   Luna 02
Zeebrugge 24/03/18   Zee 24/03/18


Name

LUNA

Previous names

1991 - 11/2006 Lydia Kosan

2006 - 10/2011 Sigas Lydia

10/2011 - 03/2018 B Gas Lydia

Type

Liquefied gas tanker - LPG

IMO-number

9043457

Call sign

OZ2180

Flag

Faeroe Islands

Port of registry

Torshavn

Previous flags

United Kingdom

2009 - 2011 Republic of Singapore

2011 - 2018 Malta, Valletta - call sign: 9HA2931

GT

2.223 t

DWT

2.003 t

NT

666 t

Length

74,00 m overall

66,55 m between perpendiculars

Breadth

14,00 m

Draught

Summer: 4,96 m

Air draft

21,90 m ballast

Depth

6,10 m

Speed

12,5 knots

Built

1993

Date of completion

15/03/1993

Builder

Hermann Sürken Schiffswerft GmbH & Co.KG

Papenburg

Germany

Yard number

378

Hull material

Steel

Hull type

Double hull

Watertight compartments

6

Continuous decks

2

Main engine

1x MAN B&W - 4 stroke 6 cylinder 280 x 320 mm combustion engine 1.470 kW / 1.997 hp at 775 rpm

Built: 1992

Propellers

1x Controllable pitch propeller - aft at 201 rpm

Electric installations

Power voltage: 440 V

Lighting voltage: 220 V

Frequency: 60 Hz

Shaft generator

1x 485 kVA - 388 kW

Generators

3x Diesel generatorsets each 243 kVA - 194 kW - 289 hp

Bow thruster

1x Brunvoll FU-37 LTC - 220 kW, forward

Number of cargo tanks

2

Tank 1: 1.134,09 m³

Tank 2: 626,48 m³

Total: 1.760,57 m³

Cargo pumps

1x Svanehoej 150/150-3-K-L - 220 m³/h

Minimum temperature

-48°C

Pressure

7,5 bar

Cargo refrigeration

2x Sabroe each 334 m³/h

Tank capacities

Fuel oil: 343 m³

Lifting equipment

1x Crane - SWL 0,9 t

Crew size

12

Previous managers

B-Gas A/S (Bergshav management A/S), Copenhagen - Denmark

Previous owners

Lauritzen Kosan A/S , Copenhegen - Denmark

B Gas Limited, Nicosia - Cyprus

Latest data adjustment

10 October 2024
