| Westerschelde 18 January 2020 |
|
Name |
FEDERAL CARDINAL |
|
Type |
Bulk carrier - Strengthened for heavy cargo loading Supramax |
|
IMO-number |
9732163 |
|
Call sign |
3FWE3 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GRT |
32.750 t |
|
DWT |
Summer: 57.981 t Winter: 56.442 t |
|
NRT |
19.097 t Panama: 30.605 t |
|
Length |
189,93 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 12,95 m Winter: 12,98 m |
|
Moulded L x B x D |
185,50 x 32,26 x 18,40 m |
|
Registered L x B x D |
185,72 x 32,26 x 18,40 m |
|
Freeboard |
Summer: 5.498 mm |
|
Depth |
18,40 m moulded |
|
Speed |
Max: 15,8 knots 14,0 knots laden 14,7 knots ballast |
|
Built |
2015 |
|
Keel laid |
25/06/2014 |
|
Launch date |
22/01/2015 |
|
Date of completion |
07/04/2015 |
|
Builder |
Shin Kurushima Toyohashi Shipbuilding Co., Ltd. |
|
Yard number |
3690 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W/Mitsui 6S50ME-B9 - 2 stroke single acting 6 cylinder 500 x 2.214 mm combustion engine 8.100 kW / 11.013 hp at 108,0 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works - Japan |
|
Propeller shaft |
1x oil lubrication shaft without monitoring device Diameter: 500 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,69 MPa Evaporation: 2,16 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
4x Generatorsets total 1.940 kVA |
|
Number of holds |
5 Hold 1: 28,18 x 11,40/23,66 m Hold 2: 28,22 x 23,66 m Hold 3: 28,22 x 23,66 m Hold 4: 28,22 x 23,66 m Hold 5: 28,15 x 23,66/10,00 m |
|
Cargo hold capacity |
Bale: 70.174 m³ Grain: 73.132 m³ |
|
Number of hatches |
Hatch 1: 17,40 x 19,20 m Hatch 2: 20,80 x 19,30 m Hatch 3: 20,80 x 19,30 m hatch 4: 20,80 x 19,30 m Hatch 5: 20,80 x 19,20 m |
|
Hatch type |
Folding weather-tight steel |
|
Max permitted loads |
Tanktop: Hold 1: 22,0 t/m² Hold 2: 17,0 t/m² Hold 3: 26,5 t/m² Hold 4: 17,0 t/m² Hold 5: 22,0 t/m² |
|
Tank capacities |
IFO: 1.693 m³ MDO: 613 m³ Fresh water: 358 m³ |
|
Cargo gear |
4x Electro-hydraulic deck cranes - SWL 30,5 t each 4x Grabs each 12,0 m³ |
|
Commercial manager |
Fednav Ltd. Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
ISM manager |
MMSL Japan Ltd. 7-1, Nihonbashi 2-chome, Chuo-ku Tokyo, 103-6060 Japan |
|
Registered owner |
Vegabulk Shipholding SA Care of Fednav Ltd Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
Renamed |
2022 Crimson Delight Republic of Panama, Panama City - Call sign: 3FWE3 Owner: Vegabulk Shipholding SA Manager: MMSL Japan Ltd. |
|
Latest data adjustment |
28 November 2022 |
