| Westerschelde 19 August 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Antwerpen 15/07/12 | Antwerpen 15/07/12 | Antwerpen 15/05/18 | Antwerpen 06/01/20 | Westerschelde 24/04/17 | Westerschelde 28/03/17 | |||||
|
Name |
DOLE ASIA |
|
Type |
Refrigerated cargo ship |
|
IMO-number |
9046526 |
|
Call sign |
C6FS4 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
Previous flags |
1994 - 2001 Liberia, Monrovia - Call sign: ELQV2 |
|
GT |
10.584 t |
|
DWT |
Summer: 10.288 t |
|
NT |
5.060 t |
|
Number of 20ft containers |
192 |
|
Reefer plug |
132 |
|
Length |
150,30 m overall 138,50 m between perpendiculars |
|
Breadth |
22,60 m extreme |
|
Draught |
9,119 m |
|
Depth |
13,25 m |
|
Speed |
21,2 knots |
|
Built |
1994 |
|
Keel laid |
05/07/1993 |
|
Launch date |
26/11/1993 |
|
Date of completion |
30/09/1994 |
|
Builder |
Stocznia Gdanska S.A. ul. Na Ostrowiu 15/20 PL-80-873 Gdansk Poland |
|
Yard number |
B369/II/3 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
Transverse bulkheads: 6 |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 6S60MC - 2 stroke 6 cylinder 600 x 2.292 mm combustion engine Mcr 11.412 kW / 15.516 hp at 105,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, vertical shell type VX818 - 8,0 bar 1x Auxiliary boiler, exhaust gas water tube type LA838 - 8,0 bar Builder: Stocznia Gdanska S.A. |
|
Generators |
4x Ulstein-Bergen KRG-6 diesel generatorsets each 1.375 kVA - 440 Volt 60 Hz |
|
Emergency generator |
1x MAN DO226MLE diesel generatorset 124 kVA - 220 Volt 60 Hz |
|
Bow thruster |
1x 740 kW |
|
Number of holds |
4 |
|
Number of temp. zones |
8 |
|
Cargo capacity |
14.838 m³ refrigerated space |
|
Hatches and hatch covers |
Hydraulically operated type: multi folding, dim. 12,45 x 8,50 m Hydraulically operated type: end folding, dim. 12,45 x 5,50 m Hydraulically operated type: end folding, dim. 12;40 x 8.50 m |
|
Stowage floor area |
5.828 m² |
|
Number of Euro-pallets |
4.502 |
|
Tank capacities 100% |
Heavy fuel oil: 1.589 m³ Diesel oil: 182 m³ Lub oil: 103 m³ Fresh water: 166 m³ Ballast water: 1.456 m³ |
|
Lifting equipment |
2x Electro - hydraulic drive cranes - SWL 32 t each 2x Electro - hydraulic drive cranes - SWL 8 t each |
|
Crew size |
26 |
|
Manager |
Reefership Marine Services Ltd. piso 6, Edificio Las Terrazas B, Centro Corporativo Plaza Roble, Guachipelin de Escazu San Jose Costa Rica |
|
Previous managers |
1994 - 2003 Reefership Marine Services Ltd. c/o DFFI Ltd. Operations and Transportation Div. MIA C, Doral United States |
|
Operator |
Dole |
|
Registered owner |
Ventura Trading Limited Care of Reefership Marine Services LLC piso 6, Edificio Las Terrazas B, Centro Corporativo Plaza Roble, Guachipelin de Escazu San Jose Costa Rica |
|
Previous owners |
1994 - 2000 Reefership Marine Services Ltd. c/o DFFI Ltd. Operations and Transportation Div. MIA C, Doral - United States 2000 - 2002 Wilmington Trust Company, Wilmington - United States 2002 - 2005 Dole Fresh Fruit International, Limited c/o Reefership Marine Services - Liberia |
|
Latest data adjustment |
10 April 2020 |
