| Zeebrugge 15 November 2010 |
 |
 |
 |
||
| Zeebrugge 02/03/09 | Zeebrugge 15/11/10 | Zeebrugge 15/11/10 |
|
Name |
HANSA BREMEN |
|
Type |
Refrigerated cargo - Equipped for carriage of cars, equipped for carriage of containers |
|
IMO-number |
8802088 |
|
Official number |
90299 |
|
Call sign |
ELWO6 |
|
Flag |
Liberia |
|
Previous flag |
18.01.1999 - Germany |
|
Port of registry |
Monrovia |
|
GT |
10.842 t |
|
Summer DWT |
12.942 t |
|
NT |
6.381 t |
|
Container capacity |
On deck: 206 TEU or 102 FEU + 2 TEU |
|
Reefer plugs |
78 on weatherdecks |
|
Length |
156,53 m overall |
|
Breadth |
23,04 m overall |
|
Draught |
Summer: 9,53 m |
|
Forecastle |
44,36 m |
|
Freeboard |
3.690 mm |
|
Depth |
13,20 m |
|
Speed |
21,0 knots |
|
Built |
1989 |
|
Keel laid |
31.07.1988 |
|
Launch date |
17.12.1988 |
|
Date of build |
01.03.1989 |
|
Builder |
Bremer Vulkan AG Schiffbau und Maschinenfabrik |
|
Yard number |
60 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Single hull |
|
Main engine |
1x Bremer Vulkan B&W 7L 60 MC - 2 stroke single acting 7 cylinder diesel engine, - 11.220 kW / 15.259 hp |
|
Number of screws |
1x Solid propeller (keyless) - aft |
|
Holds / Hatches / Compartments |
4 / 4 / 16 |
|
Cargo capacity |
Grain: 15.980 m³ |
|
Floorspace |
6.653 m² |
|
Ventilation |
Vertical |
|
Air changes |
90 |
|
Cargo gear |
4x Cranes 18 t or |
|
Tank capacities |
Ballast: 1.610 m³ |
|
Crew |
20 |
|
Manager |
Leonhardt & Blumberg Schiffahrtsgesellschaft mbH & Co.KG |
|
Charter |
Seatrade Groningen B.V. |
|
Owner |
Schiffahrts-Gesellschaft "HAMME" mbH & Co. KG |
