Antwerpen 28 December 2017 |
 |
 |
|
| Antwerpen 28/12/17 | Antwerpen 28/12/17 |
|
Name |
HANNAH S |
|
Previous names |
2008 - 2017 Normed Antwerpen |
|
Type |
Multi-Purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9351361 |
|
Call sign |
E5U3296 |
|
Flag |
Cook Islands |
|
Port of registry |
Avatiu |
|
Previous flags |
Antigua & Barbuda, St. John’s - Call sign: V2DG9 |
|
GT |
8.407 t |
|
DWT |
Summer: 11.184 t |
|
NT |
4.215 t |
|
Number of 20ft containers |
669 |
|
Length |
129,58 m overall 121,32 m registered |
|
Breadth |
19,02 m registered |
|
Draught |
8,70 m |
|
Forecastle |
28,31 m |
|
Poop |
19,68 m |
|
Freeboard |
2.960 mm |
|
Depth |
11,65 m moulded |
|
Speed |
16,0 knots |
|
Built |
2008 |
|
Keel laid |
07.07.2007 |
|
Launch date |
19.11.2007 |
|
Date of completion |
11.02.2008 |
|
Builder |
Daehan Shipbuilding Co., Ltd. |
|
Yard number |
H505 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
11 |
|
Continuous decks |
2 |
|
Main engine |
1x MaK 6 M43C - 4 stroke 6 cylinder 430 x 610 mm diesel engine - 6.000 kW at 500 rpm Year of manufacture: 2006 Manufacturer: Caterpillar Motoren GmbH & Co. KG |
|
Propellers |
1x Controllable pitch propeller - aft at 124 rpm |
|
Boilers |
1x Steam boiler, oil fired - 8,83 bar Heating surface: 15,0 m² 1x Steam boiler, exhaust gas heated - 8,83 bar Heating surface: 72,0 m² Year of manufacture: 2007 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) |
|
Electric installations |
3x Plant each 450 V - 450 kVA 1x Plant 450 V - 875 kVA 1x Plant 450 V - 125 kVA 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 215 Ah |
|
Shaft generator |
1x 875 kVA |
|
Generators |
3x Main diesel generatorsets each 704 kVA - 563 kW - 599 hp |
|
Emergency generator |
1x Diesel generatorset 156 kVA - 125 kW - 152 hp |
|
Batteries |
1x Battery for start emergency engine 215 Ah 1x Battery for emergency lighting 200 Ah 1x Battery for UPS radio 200 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 32,4 bar 1x Receiver 60 litres - 30,0 bar 1x Receiver 150 litres - 7,5 bar |
|
Bow thruster |
1x Transverse thruster - 500 kW, forward |
|
Cargo capacity |
Bales: 13.565 m³ Grain: 14.237 m |
|
Holds |
Dimensions hold No.1: 18,90 x 15,60 x 11,00 m Dimensions hold No.2: 58,20 x 15,60 x 11,00 m (3 compartments in hold 2) |
|
Hatches |
Dimensions hatch No.1: 18,90 x 15,60 m Dimensions hatch No.2 : 58,20 x 15,60 m |
|
Type of hatch covers |
Pontoon type - 13 pieces |
|
Max. permitted loads |
Tank top strength: 18 t/m² |
|
Tank capacities |
Fuel oil: 1.051,2 m³ |
|
Anchor equipment |
3x Anchors weight each 4.590 kg Chain length: 550,00 m |
|
Cargo gear |
2x Liebherr cranes SWL each 60,0 t Combinable at 120 t |
|
Manager |
Strahlmann Reederei |
|
Previous managers |
Universal Marine B.V., Krimpen aan den IJssel - The Netherlands |
|
Registered owner |
Clean Shipping Ltd. |
|
Previous owners |
M.S. North C.V., 3089 JN Rotterdam - The Netherlands MV "ANTWERPEN" C.V., 3089 JN Rotterdam - The Netherlands |
|
Latest data adjustment |
18 March 2018 |
