| Antwerpen 27 May 2012 |
 |
| Westerschelde 09/03/20 |
|
Name |
NORDFJORD |
|
Previous names |
03/2006 - 12/2008 Jan Van Gent |
|
Type |
General cargo ship -heavy cargo - Container ship |
|
IMO-number |
9341732 |
|
Call sign |
PHFB |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
Previous flag |
03/2009 - 12/2008 The Netherlands, Alkmaar - Call sign: PHFB |
|
GT |
3.990 t |
|
DWT |
Summer: 6.100 t |
|
DWCC |
Summer: 5.550 t Winter: 5.400 t |
|
NT |
2.208 t |
|
Number of 20ft containers |
242 |
|
Length |
110,98 m overall 105,48 m between perpendiculars |
|
Breadth |
14,00 m |
|
Draught |
6,09 m |
|
Air draft |
21,00 m ballast |
|
Freeboard |
2.054 mm |
|
Depth |
8,13 m moulded |
|
Speed |
13,0 knots |
|
Built |
2006 |
|
Keel laid |
26/07/2005 |
|
Launch date |
03/02/2006 |
|
Date of completion |
09/03/2006 |
|
Builder |
Scheepswerf Ferus Smit B.V. Westerbroek The Netherlands |
|
Yard number |
363 |
|
Hull material |
Steel |
|
Watertight compartments |
9 |
|
Bulkheads |
2x Movable, can be placed in 4 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke single acting 8 cylinder 225 x 400 mm combustion engine 2.640 kW / 3.587 bhp at 750 rpm Built: 2005 Builder: Caterpillar Motoren GmbH & Co. KG, kiel - Germany |
|
Propellers |
1 |
|
Electrical propulsion gen. |
1x 390 kW - 400 Volt |
|
Propelling system |
1x Screw propeller controllable pitch at 200 rpm |
|
Electrical installation |
Power voltage: 400 V Lighting voltage: 230 V Frequency: 50 Hz |
|
Generators |
2x Diesel generatorsets each 175 kVA - 140 kW - 222 hp |
|
Emergency generator |
1x Diesel generatorset 52 kVA - 42 kW - 68 hp |
|
Bow thruster |
1x 340 kW |
|
Number of holds |
2 Dimension: Hold 1: 27,58 x 11,47 x 9,00 m Hold 2: 50,88 x 11,47 x 9,00 m |
|
Total capacity of holds |
7.946 m³ Grain: 278.042 ft³ Bales: 280.494 ft³ |
|
Hold ventilation |
6x Air-changes per hour |
|
Cargo Hatchways |
2 Dimension: Hatch 1: 27,55 x 11,47 m Hatch 2: 50,88 x 11,47 m |
|
Hatch type |
Pontoon hatches with gantry crane |
|
Max permitted loads |
Tanktop: 15,0 t/m² On deck: 2,0 t/m² |
|
Fuel capacity |
400 m³ |
|
Manager |
Wagenborg Shipping Delfzijl The Netherlands |
|
Owner |
Eems Beheer IX B.V. Delfzijl The Netherlands |
|
Previous names & owners |
03/2006 - 12/2008 Jan Van Gent - Rederij B. Kok (Wagenborg Shipping BV), Alkmaar - The Netherlands 12/2008 - 09/2020 C.V. m.s. Nordfjord II, Delfzijl - The Netherlands |
|
Latest data adjustment |
23 June 2022 |
