| Westerschelde 09 October 2012 |
 |
 |
 |
 |
|||
| Antwerpen 29/03/13 | Antwerpen 29/03/13 | Antwerpen 05/03/14 | Westerschelde 14/07/14 |
|
Name |
SLOMAN DISCOVERER |
|
Type |
Multi-Purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9620669 |
|
Call sign |
V2FO2 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
9.611 t |
|
DWT |
12.641 t |
|
NT |
4.260 t |
|
Number of 20ft containers |
665 |
|
Container capacity 14t |
524 |
|
Reefer plug |
25 sockets - max. 50 reefers via splitters |
|
Length |
138,01 m overall 130,71 m registered |
|
Breadth |
21,00 m registered |
|
Draught |
8,00 m |
|
Freeboard |
3.018 mm |
|
Depth |
11,00 m moulded |
|
Speed |
15,0 knots |
|
Built |
2012 |
|
Keel laid |
20.11.2008 |
|
Launch date |
25.07.2011 |
|
Date of completion |
06.01.2012 |
|
Builder |
Jiangzhou Union Shipbuilding Co., Ltd. |
|
Yard number |
JZ1040 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
6 |
|
Continuous decks |
2 |
|
Main engine |
1x Mak 6M43C - 4 stroke 6 cylinder 430 x 610 mm diesel engine - 5.400 kW at 500 rpm Year of manufacture: 2011 Manufacturer: Caterpillar Motoren Rostock GmbH |
|
Propellers |
1x Controllable pitch propeller - aft at 130 rpm |
|
Boilers |
1x Thermal oil heater, exhaust gas heated - 10, bar Heating surface: 88,6 m² Year of manufacture: 2010 1x Thermal oil heater, oil fired - 13,0 bar Heating surface: 39,0 m² Year of manufacture: 2011 Manufacturer: Alfa Laval Aalborg B.V. |
|
Electric installations |
3x Plants each 400 V - 493 kVA 1x Plant 400 V - 875 kVA 1x Plant 400 V - 124 kVA 2x Plants each24 V - 160 Ah 1x Plant 24 V - 195 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah |
|
Shaft generator |
1x 875 kVA |
|
Generators |
3x Diesel generatorsets each 493 kVA |
|
Emergency generator |
1x Diesel generatorset 124 kVA |
|
Batteries |
1x Battery for UPS navigation 200 Ah 1x Battery for automation 200 Ah 1x Battery for UPS radio 195 Ah 2x Batteries for start emergency engine each 160 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 33,0 bar 1x Receiver 160 litres - 33,0 bar 1x Receiver 30 litres - 33,0 bar 1x Receiver 1.000 litres - 11,0 bar 1x Receiver 250 litres - 11,0 bar |
|
Bow thruster |
1x Transverse thruster - 500 kW, forward |
|
Number of holds |
3 |
|
Cargo capacity |
15.953 m³ |
|
Anchor equipment |
3x Anchors weight each 4.590 kg Chain length: 550,00 m |
|
Cargo gear |
2x Cranes - SWL 150 t each combinable up to 300 t |
|
Crew size |
20 |
|
Manager |
Sloman Neptun Schiffahrts-Aktiengesellschaft |
|
Operator |
Sloman Neptun |
|
Registered owner |
Sloman Neptun Schiffahrts-Aktiengesellschaft |
|
Renamed |
Sun Discoverer Antigua & Barbuda, St. John’s - Call sign: V2FO2 Owner: Sloman Neptun Schiffahrts-Aktiengesellschaft Manager: Sloman Neptun Schiffahrts-Aktiengesellschaft |
|
Last update |
13.November 2017 |
