Westerschelde 13 November 2017 |
 |
 |
 |
||
| Westerschelde 02/12/15 | Westerschelde 09/03/19 | Westerschelde 28/05/20 | ||
|
Name |
HEKLA |
|
Type |
Multi-purpose dry cargo ship - Container ship - Heavy cargo |
|
IMO-number |
9356505 |
|
Call sign |
PHPD |
|
Flag |
The Netherlands |
|
Port of registry |
Ten Boer |
|
GT |
2.281 t |
|
DWT |
3.592 t |
|
DWCC |
Summer: 3.442 t |
|
NT |
1.229 t |
|
Number of 20ft containers |
104 |
|
Length |
88,97 m overall 88,99 m between perpendiculars |
|
Breadth |
11,80 m moulded |
|
Draught |
Summer: 5,40 m Winter: 5,29 m |
|
Keel to mast end |
24,50 m |
|
Air draft |
18,00 m in ballast |
|
Freeboard |
1.360 mm |
|
Depth |
6,90 m moulded |
|
Speed |
Service: 10,0 knots |
|
Built |
2008 |
|
Date of completion |
16/05/2008 |
|
Builder casco |
Lodenice Nova Melnik s.r.o. Melnik Czech Republic |
|
Builder |
Scheepswerf Bijlsma Lemmer B.V. Lemmer The Netherlands |
|
Yard number |
752 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8L20C - 4 stroke single acting 8 cylinder 200 x 280 mm combustion engine 1.440 kW / 1.957 hp at 1.000 rpm Built: 04/11/2006 |
|
Propellers |
1x Controllable pitch propeller |
|
Shaft generator |
1x 390 kVA - 312 kW |
|
Generators |
1x Main diesel generatorset 175 kVA - 140 kW - 204 hp |
|
Emergency generator |
1x Diesel generatorset 38 kVA - 30 kW - 72 hp |
|
Bow thruster |
1x 360 kW |
|
Number of holds |
1 63,00 x 9,60 x 7,50 m |
|
Total capacity of holds |
4.501 m³ |
|
Number of hatches |
1 63,00 x 9,60 m |
|
Tank capacities |
HFO: 225 m³ MDO: 35 m³ Water ballast: 1.282 m³ Fresh water: 44 m³ |
|
Manager |
Wagenborg Shipping B.V. Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Registered owner |
Martin J. Langevoort en Teun A.P. Vogelij Ten Boer The Netherlands |
|
Latest data adjustment |
11 May 2022 |
