Westerschelde 03 May 2019 |
 |
 |
 |
 |
 |
||||
| Westerschelde 03/05/19 | Westerschelde 20/08/15 | Westerschelde 20/08/15 | Antwerpen 31/12/19 | Westerschelde29/07/19 | ||||
|
Name |
FRANK |
|
Type |
Chemical tanker |
|
IMO-number |
9204049 |
|
Call sign |
ZDEF5 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
9.266 t |
|
DWT |
Summer: 14.895 t |
|
NT |
4.595 t |
|
Length |
137,79 m overall 126,07 m between perpendiculars |
|
Breadth |
22,00 m extreme |
|
Draught |
Max: 9,20 m |
|
Speed |
13,8 knots |
|
Built |
2000 |
|
Keel laid |
01/03/1999 |
|
Launch date |
11/02/2000 |
|
Date of completion |
27/06/2000 |
|
Builder |
Union Naval De Levante S.A. Astilleros De Valencia Valencia Spain |
|
Yard number |
270 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Krupp/MaK 9M32 - 4 stroke 9 cylinder combustion engine 4.320 kW / 5.870 hp Builder: Krupp Mak Motoren GmbH & Co.KG, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated 1x Thermal oil heater, oil fired |
|
Shaft generator |
1x 1.375 kVA |
|
Generators |
2x Wärtsilä 6L170 main diesel generatorset each 800 kVA |
|
Emergency generator |
1x Diesel generatorset 430 kVA |
|
Bow thruster |
1x 588 kW |
|
Number of cargo tanks |
12 |
|
Cargo hold capacity |
16.495 m³ |
|
Tank capacities |
Ballast: 6.905 m³ |
|
Anchor equipment |
Length: 275,00 m Diameter: 56 mm |
|
Crew size |
16 |
|
Manager |
Carl F. Peters (GmbH & Co.) KG Kurze Mühren 13 20095 Hamburg Germany |
|
Registered owner |
Reederei TMS "FRANK" GmbH & Co. KG Bargteheide Germany |
|
Renamed |
2020 Ophelia I Republic of Panama, Panama City - Call sign: 3EMM9 Registered owner: Frank Shipping Inc. Manager: Callista Shipping Services Inc., Dubai - United Arab Emirates (UAE) |
|
Latest data adjustment |
16 January 2024 |
