| Westerschelde 11 November 2015 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 11/11/15 | Westerschelde 19/02/14 | Westerschelde 16/01/12 | Westerschelde 16/01/12 | Westerschelde 08/08/18 | Westerschelde 08/05/18 | |||||
|
Name |
FRANCES WONSILD |
|
Type |
Oil tanker - Chemical tanker |
|
IMO-number |
9013660 |
|
Call sign |
IBFW |
|
Flag |
Italy |
|
Port of registry |
Augusta |
|
GT |
2.349 t |
|
DWT |
Summer: 2.698 t |
|
NT |
816 t |
|
Length |
89,60 m overall 80,90 m between perpendiculars |
|
Breadth |
14,00 m |
|
Draught |
5,21 m |
|
Freeboard |
1.361 mm |
|
Depth |
6,55 m |
|
Speed |
13,5 knots |
|
Built |
1994 |
|
Keel laid |
23/10/1989 |
|
Date of completion |
01/08/1994 |
|
Builder |
Societa' Esercizio Cantieri S.P.A. Viareggio Italy |
|
Yard number |
766 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Number of partial decks |
6 |
|
Main engine |
1x Yanmar 6N330-EN - 6 cylinder combustion engine 2.208 kW / 3.000 hp at 620 rpm Built: 1991 Builder: Yanmar Co., Ltd., Osaka - Japan |
|
Propellers |
1x Controllable pitch propeller- aft at 184 rpm |
|
Boilers |
2x CHO Wiesloch - 6,8 bar 1x CHR Wiesloch - 6,8 bar |
|
Shaft generator |
1x 688 kVA - 550 kW |
|
Generators |
1x Main diesel generatorset 313 kVA - 250 kW - 408 hp 2x Main diesel generatorsets each 563 kVA - 450 kW - 611 hp |
|
Emergency generator |
1x Diesel generatorset 44 kVA - 35 kW - 60 hp |
|
Number of cargo tanks |
14 |
|
Cargo tank capacity |
3.031 m³ |
|
Cargo handling |
14x Pumps each 150 m³/h |
|
Heating capacity |
70°C |
|
Manager |
M.E. Marittima Emiliana S.P.A |
|
Registered owner |
M.E. Marittima Emiliana S.P.A Via Adua, 4 96011 Augusta SR Italy |
|
Group |
Amoretti Armatori group |
|
Renamed |
05/2023 Sild Saint Kitts and Nevis, Basseterre - Call sign: V4DY5 Owner & manager: Marchem Trans DMCC, Dubai - United Arab Emirates |
|
Last data adjustment |
27 August 2024 |
