Name |
CITRUS VITA BRASIL |
|
Previous names |
2009 - 2018 Hermes Arrow |
|
Type |
Fruit Juice tanker - Refrigerated cargo carriage |
|
IMO-number |
9491836 |
|
Call sign |
D5LW3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
Hong Kong, China - Call sign: VRFB2 |
|
GT |
30.912 t |
|
DWT |
34.965 t |
|
NT |
9.274 t |
|
Length |
210,56 m overall 198,74 m between perpendiculars |
|
Breadth |
29,88 m extreme |
|
Draught |
Summer: 11,40 m |
|
Keel to mast end |
50,55 m |
|
Depth |
16,40 m |
|
Speed |
Max: 21,9 knots |
|
Keel laid |
20/11/2008 |
|
Launch date |
03/03/2009 |
|
Date of completion |
18/06/2009 |
|
Builder |
Volkswerft Stralsund GmbH Stralsund Germany |
|
Yard number |
482 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 7L70ME-C - 2 stroke 7 cylinder 700 x 2.360 mm combustion engine 21.469 kW / 29.189 hp at 108,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1x Auxiliary boiler, composite |
|
Generators |
3x Hyundai/Himsen 8H25/33 main diesel generatorsets each 1.805 kW |
|
Harbour generator |
1x Cummins TA38-DM1 diesel generatorset |
|
Emergency generator |
1x SISU 645 DSBIG diesel generatorset |
|
Bow thruster |
1x 1.100 kW |
|
Tank capacities |
Ballast: 9.402,6 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 76 mm |
|
Crew |
22 |
|
Manager |
Citrosuco Europe N.V. Geeraard van Den Daelelaan 9000 Gent Belgium |
|
Registered owner |
Citrus Vita Brasil Shipping Co. Monrovia Liberia |
|
Previous names & owners |
2009 - 2018 Hermes Arrow - White Dolphin Sg Ltd. |
|
Remarks |
25/10/2018 Converted containership Hermes Arrow into a juice carrier |
|
Latest data adjustment |
10 February 2022 |
