Westerschelde 11 January 2020 |
|
Name |
ODIN |
|
Previous names |
1998 - 10/2005 Dicksi 10/2005 - 10/2010 Tarndal |
|
Type |
Oil/Chemical tanker |
|
IMO-number |
9151890 |
|
Call sign |
UIHY |
|
Flag |
Russia |
|
Port of registry |
Saint-Peterburg |
|
Previous flags |
1998 - 2011 Denmark, Skagen - Call sign: OWQA2 |
|
GT |
5.685 t |
|
DWT |
Summer: 8.269 t |
|
NT |
2.630 t |
|
Length |
115,10 m overall 107,83 m between perpendiculars |
|
Breadth |
18,28 m |
|
Draught |
Max: 7,52 m |
|
Depth |
9,89 m |
|
Speed |
13,5 knots |
|
Built |
1998 |
|
Builder |
Qiuxin Shipyard of Jiangnan Shipbuilding Group Co. China |
|
Hull material |
Steel |
|
Hull type |
Double skin Double bottom |
|
Main engine |
1x Wärtsilä 6L38 - 4 stroke 6 cylinder combustion engine 3.960 kW at 600 rpm |
|
Propellers |
1x Controllable pitch propeller Wärtsilä type Wichman CP130, diameter 4.300 mm |
|
Boilers |
1x Exhaust boiler type Aalborg AQ 16 - 10,0 bar 1x Axillary boiler type Aalborg AQ9 8,6 - 12,0 bar |
|
Shaft generator |
1x AVK generator 1.626 kVA |
|
Generators |
2x Caterpillar 3508 diesel engines each 720 kW connected to AVK generators 900 kVA 60 Hz 1x Caterpillar 3408C diesel engine 360 kW connected to a AVK generator 438 kVA 60 Hz |
|
Emergency generator |
1x MAN DO 226 MLF diesel engine 109 kW connected to a AVK generator 125 kVA 450 Volt, 60 Hz |
|
Bow thruster |
1x Brunwoll hydraulically driven 588 kW |
|
Number of cargo tank |
2x 5 cargo tanks plus two slop tanks |
|
Cargo tank capacity 98% |
9.007 m³ |
|
Segregations |
5x Natural 1.145 m³ + 1.967 m³ + 2.289 m³ + 2.098 m³ + 1.489 m³ |
|
Pumps |
10x Frank Mohn hydraulically driven pumps, type SD 150 each 350 m³/h 1x Frank Mohn portable hydraulically driven pump, type TK-80, 80 m³/h Total simultaneous pumping capacity 2.100 m³/h 2x Frank Mohn type VH-200 ballast pumps each 350 m³/h |
|
Tank capacities |
Ballast: 3.781 m³ HFO: 422 m³ Diesel oil: 145 m³ fresh water: 278 m³ |
|
Lifting equipment |
2x Dregger deck cranes: SWL 3,0 t aft SWL 2,0 t fore |
|
Accommodation |
Living quarters situated aft with public room and 6 Single cabins with separate bedrooms/toilets/bathrooms 8x Single cabins with toilets/bathrooms. |
|
Registered owner |
Kontur-SPB OOO 195248, Gorod Sankt-Peterburg, Pereulok Umanskiy, d. 76 Russia |
|
Previous names & shipping companies |
1998 - 2005 Dicksi - Stenstraum A/S 2005 - 2010 Tarndal - Tarntank Rederi AB 2010 - 2018 Tarndal - Tarnshipping AS |
|
Latest data adjustment |
29 March 2020 |
