Multratug 17 - IMO 9481752

Name

MULTRATUG 17

Previous name

Launch as: Isaogullari Vega 12

Type

Tug boat - Fire fighting ship - Salvage tug - Water spraying

IMO-number

9481752

Call sign

PHPV

Flag

The Netherlands

Port of registry

Terneuzen

GT

498 t

NT

149 t

Length

35,70 m overall

30,54 m between perpendiculars

Breadth

11,50 m

Draught

Summer: 4,35 m

Freeboard

1.258 mm

Speed

13,5 knots

Built

2008

Date of completion

16/05/2008

Builder

Vega Denizcilik Shipyard

Sanayi

Turkey

Yard number

12

Hull material

Steel

Hull type

Single hull

Main engine

2x Caterpillar 3516B HD - 6 cylinder internal combustion engines each 1.920 kW / 2.609 hp total 3.840 kW / 5.218 hp at 1.600 rpm

Builder: Caterpillar Inc.

Propulsion

2x Azimuth stern drive thruster Schottel SRP 1515CP controllable pitch

Diameter: 2.600 mm

Generators

3x Volvo Penta D7 TA diesel generatorsets each 174 kVA - 139 kW - 189 hp at 1.500 rpm

3x 400 Volt, 50 Hz, 3 ph

Bow thruster

150 kW, electric driven

Bollard pull

70 t

FIFI 1 System

2x Centrifugal, main engine driven - Capacity 1.350 m³/h each

Deck lay-out

• Anchor: 2x 780 kg

• Chain: Diameter 24 mm, U2 / 206 m

• Double drum winch: DMT TW-H450KN

• Capacity: 1x 1.000 m - 52 mm, 1x 750 m – 52 mm

• Brake holding capacity: 150 tons on the 5th layer

• Stern roller: 130 tons SWL 3,00 m x 1,00 m

• Towing pin: DATA DTH 65T – 130T

• Bridle winch: Schraven Maritiem, 27 tons

• Fwd towing winch: 1

• Deck crane: Hydraulic 1 ton @ 13,00 m

Tank capacities

Fuel oil: 313,0 m³ m³

Fresh water: 48,0 m³

Lubrication oil : 5,0 m³

Hydraulic oil : 5,0 m³

Dirty oil : 4,0 m³

Bilge water : 4,0 m³

Accommodation

3x Man cabin

1x 2-men cabin

2x 4-men cabin

1x Messroom

1x Galley

Operator

Multraship Towage & Salvage B.V.

Owner

Multraship Towage & Salvage B.V.

Schuttershofweg 1

4530 AB Terneuzen

The Netherlands

Previous owner

2007 - 2008 Vega Shipyard Ltd.

Bandirma

Turkey

Latest data adjustment

22 May 2021
