Neptun 9 - IMO 9448085

Name

NEPTUN 9

Type

Tug boat - Offshore tug - Supply ship

IMO-number

9448085

Call sign

PBBV

Previous call sign

HO4792

Flag

The Netherlands

Previous flag

Republic of Panama

Port of registry

Hardinxveld

Previous port of registry

Panama City

GT

454 t

DWT

500 t

NT

136 t

Length

36,50 m overall

36,00 m between perpendiculars

32,77 m waterline

Breadth

10,40 m

Draught

Lightship: 3,80 m

Maximum draught: 4,15 m

Freeboard

1.212 mm

Depth

5,00 m midships

Speed

11,6 knots

Built

2007

Date of completion

12.12.2007

Builder

Guangdong Machinery Import & Export Co.,Ltd.
Guangzhou
China

Yard number

GMG0511

Hull material

Steel

Hull type

Single hull

Watertight compartments

5

Continuous decks

1

Main engine

2x Cummins KTA-50-M2 - 4 stroke 16 cylinder 159 x 159 mm diesel engines - 2.388 kW / 3.244 hp at 1.800 rpm

Built: 2006

Builder: Cummins Diesel UK, Cardiff - United Kingdom

Propelling system

2x Screw propeller solid - at 302 rpm

Generators

2x Cummins diesel generatorsets each 120 kVA - 96 kW - 166 hp

Bow thruster

320 kW

Bollard pull

42,0 t

Deck cargo capacity

6x 20ft containers – 90 t

Clear deck area

120 m²

Cargo deck load

5 t/m²

Towing winch

Double drum waterfall

Tow wires: 2 x 700 m

Tow wire diameter: 40 mm

Tank capacities

Gas oil: 320.000 litres

Fresh water: 150.000 litres

Marine crane

1x Crane - SWL 14 t at 2,00 m

Navigation & radio Radar

Echosounder

Speed log

GPS

Autopilot

2x Compass

AIS

Navtex

Sart

Epirb

VHF

SSB

Inmarsat C + GMDSS A3

Crew

6

Manager

Dutch International Towage Company B.V.

Deepsea-towage, offshore supply and anchorhandling services

"LANDFALL" Transport & Towage BV

Prinsenweer 25

3363 JK Sliedrecht

The Netherlands

Owner

Neptune Marine Service BV
Rivierdijk 458

3372BW Hardinxveld-Giessendam
The Netherlands

Renamed

04.2012 Nazli

Latest data adjustment

27 June 2014
