Multratug 19 - IMO 9630250

Name

MULTRATUG 19

Type

Damen ASD Tug 3212 tug

IMO-number

9630250

Call sign

PCHZ

Flag

The Netherlands

Port of registry

Terneuzen

GT

453 t

DWT

226 t

NT

135 t

Length

32,70 m overall

28,84 m between perpendiculars

Breadth

12,82 m overall

Draught

Max.: 5,50 m

Speed

Max;: 15,0 knots

Built

2012

Launch date

22/10/2011

Builder

Damen Shipyard Galati

Galati

Romania

Yard number

512509

Hull material

Steel

Hull type

Single hull

Number of decks

1

Main engine

2x Caterpillar 3516C HD TA/D diesel engines - 5.050 kW / 6.772 bhp at 1.800 rpm

Built: 2012

Propulsion

2x Azimuth thrusters Rolls Royce US 255 CP

Propeller type

Controllable pitch - 2.800 mm diameter

Generators

2x Caterpillar 6,6 TA main diesel generatorsets each 125 kVA - 230/400 Volt 50 Hz

Bollard pull

Max.: 85 t

Deck lay-out

• Anchor / towing winch: Hydraulically driven escort winch with double drum

• Type: Maaskant T 320 –HH 2 - M2 - 22 DAM

• Capacity: 2x 200 m, diameter: 60 mm

• Brake capacity: 200 t 2nd layer

• Anchor: 2x 495 kg

• Chain: 302,50 m diameter: 22 mm

• Towing winch aft: Maaskant T320 - HHT - ESD

• Brake capacity: 200 t 2nd layer

• Capacity : 750 m, diameter: 54 mm

• Towing hook aft: 100 t

• Capstan: 5 t

Fire fighting system

2x Main engine driven pumps each 1.450 m³/h

Fifi monitors

2x Each 1.200 m³/h - water / foam

Tank capacities

Fuel oil: 135,0 m³

Fresh water: 15,2 m³

Lubrication oil: 8,1 m³

Foam: 12,5 m³

Dirty oil: 4,2 m³

Bilgewater: 6,7 m³

Sludge: 2,5 m³

Hydraulic oil: 2,8 m³

Sewage: 5,1 m³

Lifting equipment

1x Deck crane - SWL 2.200 kg at 8,60 m

Accommodation

2x 1-Man cabins

4x 2-Men cabins

1x Mess room

1x Galley

Manager

Multraship Towage and Salvage BV

Scheldekade 48

4530 AB Terneuzen

The Netherlands

Owner

Multraship Towage and Salvage BV

Scheldekade 48

4530 AB Terneuzen

The Netherlands

Latest data adjustment

06 December 2021
