Name |
PHILADELPHIA EXPRESS |
|
Previous names |
02/2003 - 09/2005 TMM Yucatan 09/2005 - 03/2006 CP Yosemite |
|
Type |
Fully self sustained cellular container vessel |
|
IMO-number |
9243203 |
|
Call sign |
WDC6736 |
|
Flag |
United States of America |
|
Port of registry |
Philadelphia, PA |
|
Previous flags |
02/2003 - 09/2005 United Kingdom, London 09/2005 - 03/2006 United States of America, Tampa, FL 03/2006 - 08/2018 |
|
GT |
40.146 t registered Suez: 41.492,55 t |
|
DWT |
Summer: 40.478 t |
|
NT |
18.097 t registered Panama: 34.934,33 t Suez: 35.580,14 t |
|
Number of 20ft containers |
On deck: 1.420 In hold: 1.817 Total: 3.237 |
|
Number of 40ft containers |
On deck: 692 + 36 TEU In hold: 881 + 59 TEU Total: 1.573 + 95 TEU |
|
Container capacity 14t |
2.370 |
|
Reefer capacity |
On deck: 282 in hold: 118 Total: 400 |
|
Length |
243,35 m overall 232,40 m between perpendiculars |
|
Breadth |
32,20 m moulded |
|
Draught |
11,02 m |
|
Freeboard |
8.540 mm |
|
Depth |
19,50 m moulded |
|
Speed |
Max.: 22,5 knots |
|
Built |
2003 |
|
Keel laid |
28/06/2002 |
|
Launch date |
17/10/2002 |
|
Delivery date |
19/02/2003 |
|
Builder |
CSBC - China Shipbuilding Corp. Kaohsiung Shipyard No.3 Jhonggang Rd, Siaogang District, Kaohsiung City, 81234 Taiwan |
|
Yard number |
794 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Watertight bulkheads |
17 |
|
Main engine |
1x MAN-B&W 8K80MC-C - 8 cylinder 800 x 2.300 mm combustion engine 29.243 kW at 104,0 rpm Manufacturer: HSD Engine Co. Ltd. |
|
Propellers |
1 Manufacturer: Hyundai Heavy Ind. Co.,Ltd. |
|
Boilers |
1x Auxiliary composite boiler - 8,0 bar 1x Unfired exhaust gas boiler 1x Fired exhaust gas boiler |
|
Generators |
3x MAN-B&W 8L27/38 main diesel generatorsets each 2.280 kW Manufacturer: Hyundai heavy Ind. Co.,Ltd. |
|
Bow thruster |
1x 1.700 kW |
|
Number of holds |
6 |
|
Hatches type |
Pontoon |
|
Number of tanks |
Ballast: 23 Fuel oil: 14 Lubricating oil: 8 Diesel oil: 5 Sludge3 Fresh water: 3 Chain: 1 Waste water: 1 |
|
Tank capacities |
Diesel Oil: 224,64 m² Freshwater: 487,32 m³ Fuel Oil: 4.305,39 m³ Lube Oil: 324,86 m³ Tank Ballast: 15.167,3 m³ |
|
Cargo gear |
4x Deck jib crane - SWL 45,0 t each |
|
Manager |
Hapag Lloyd USA 401 East Jackson Street, Suite 3300 Tampa Fl USA |
|
Operator |
Hapag-Lloyd Hamburg Germany |
|
Registered owner |
Hapag-Lloyd USA LLC |
|
Renamed |
08/2021 Spartel Trader Liberia, Monrovia - Call sign: 5LCA6 Owner: Spartel Marine SA Manager: Lomar Shipping Ltd., Bremen - Germany |
|
Latest data adjustment |
11 February 2023 |
